Two Way Revolving Door Half Height Turnstile Access Control System DC24V
  • Two Way Revolving Door Half Height Turnstile Access Control System DC24V
  • Two Way Revolving Door Half Height Turnstile Access Control System DC24V

Two Way Revolving Door Half Height Turnstile Access Control System DC24V

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-HHT01
Product Details
Material:
Full 304 Stainless Steel
Logic Voltage:
DC24V
Gate Open Signal:
Dry Contact/ Relay
Half-height Turnstile Solenoid:
DC24V
IP Rate:
IP55
Power Supply:
110V/220V; 50/60Hz
High Light:

Two Way Half Height Turnstile

,

Revolving Door Half Height Turnstile

,

DC24V Stainless Steel Turnstile

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-7working days after payment received for sample
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
3,000pcs per month
Product Description

Two Way Stainless Steel Revolving Door Half Height Turnstile Access Control system



PRODUCT DESCRIPTION



Product Name
Stainless Steel Two Way Traffic Control Revolving Door Half Height Turnstile Access Control System
Core Features
1. Turnstile Appearance: Compact and beautiful half high turn style design, superior quality and brushed surface, Thickness=1.5 mm, finest work-craft.
2. Turnstile Mechanism: Semi-auto type or (Full auto type, DC brush-less motor drive, ARM + DFC control technology.)
3. Turnstile Operation: Solid performance silent and smooth operation, easy installing and less maintenance rate.
Function
Half Height Turn Style Pedestrian Access Control Solution
Application
Kindergarden, factory, gyms, parks, clubs, campus etc.



Two Way Revolving Door Half Height Turnstile Access Control System DC24V 0



MAIN FUNCTION AND FEATURES



1. The whole system runs smoothly, long-life performance, high operation dependability and fast response.


2. The mechanism is equipped with an automatic regulated hydraulic buffer device. No noise and impact when

running.


3. Self-test function, when power on, system restoration automatic.


4. Dual-bearing device, keeping the gate in balance when there is external force.


5. Single directional or Bi-directional is selectable.


6. LED indicator supported


7. Automatic reset function: when Full Height Turnstile receives an open single, but passenger do not pass

through the hallway within a specific time (default 5s), turnstile arm will lock automatically. Limit passing time

(01-60 seconds), passing time can be set on Full Height Turnstile circuit board.


8. When power off, turnstile lane will be free to pass, complying with fire safety requirements.



9. The rotary wings will be locked automatically if the system do not receive IR signal



10. Multi-passage for variety application demands ,Cover 99% needs on earth



11. Programmable signal separate control : pass time,pass speed etc. parameters



Two Way Revolving Door Half Height Turnstile Access Control System DC24V 1



TECHNICAL SPECIFICATIONS



Item SN-HHT01
Housing Material 304 stainless steel
Standard Size L1200*W280*H1000(mm)
Drive mechanism Solenoid mechanism
Arm Length 450mm
Pass Direction single or bi-directional
Arm Driving Force 1kg
LED Light direction indication
Working mechanism 24V solenoid valve
Working Environment Indoor and Outdoor
Work temperature -20°C~60°C
Normal Running Life More than 5million
Input interface 12V pulse signal with pulse width >100ms, drive current >10mA
