Edifice Entrance Access Control Turnstiles Full Height SS304 Acrylic BLDC Motor
  • Edifice Entrance Access Control Turnstiles Full Height SS304 Acrylic BLDC Motor
  • Edifice Entrance Access Control Turnstiles Full Height SS304 Acrylic BLDC Motor

Edifice Entrance Access Control Turnstiles Full Height SS304 Acrylic BLDC Motor

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-SLB02
Product Details
Material:
SS304/Acrylic
Flap Height:
800 To 1500 Mm
Size:
1200*330*1000 Mm
Motor Type:
BLDC Motor
Motor Voltage:
DC24V
Power Input:
AC100V~240V, 50/60Hz; DC24V
Highlight:

Edifice Entrance Access Control Turnstiles

,

SS304 Acrylic Access Control Turnstiles

,

BLDC Motor Full Height Turnstiles

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T or western Union
Supply Ability
1,000 pcs per month
Product Description

Edifice Entrance Access Control International Standard Full Height Panel Baffle Gate



PRODUCT DESCRIPTION



 Sliding Barrier Turnstile Main Features:
1. Faster pass speed and better performance for anti-trailing.


2. The design of connecting rod - run smoothly without noise.


3. Anti-climb, anti-creeper, strict management and higher grade appearance which offering graceful passage.


4. Infrared anti pinch design and dormancy function when barrier is blocked to achieve a more safe passage.


5. Sound and light alarm, including illegal intrusion, enter from wrong direction, trailing and overdue passing etc.


6. Gate auto open when power is off to meet the fire protection requirements.



7. The body is made from brushed stainless steel which creates a seamless and elegant access point to

blend into most indoor environment.


8. It can be integrated with any kind of access controller system (e.g.: RFID device, Push button, Fingerprint

and Biometric device).



9. In case of emergency, the Optical Turnstile arm will open automatically to allow free passage.

Optical Turnstiles are suit for elegant and luxury entrance solutions.



10. LED direction indicator



11. Gate auto opens when power off and auto close when power on



12. Alarm function, in case of illegal intrusion and reverse intrusion, etc.





Edifice Entrance Access Control Turnstiles Full Height SS304 Acrylic BLDC Motor 0

PRODUCT SPECIFICATIONS



Model
SN-SLB02
Case Material
SS304(1.5mm, 2.0mm optional)/Baking varnish
Production Process
CNC Laser Cutting
Size
1200*330*980mm(Customization acceptable)
Power input
AC100-240V,50/60Hz; DC24V
Operation voltage
DC24V, 3A, Power: 40W( Brushless Motor Optional)
Electromagentic
Duty Cycle 100%
Passage Width
550mm
Flap Size
300*1200mm(Customization acceptable for heigth)
Flap Material
Acrylic
Passage direction
Single directional/Bi-directional(Optional)
Operating time
1S
Throughput Rate
30 persons/minute(Normally Closed)
40 persons/(Normally Open)
Reset Time after Power on
3S
MCBF
5,000,000 Cycles
Reset Time after failure
10S
Automatic Reset Function
Automatically locked within set time(Time Adjustable)
Operation Humidity
0~90%(No Freezing)
Operation Temperature
-10℃~+50℃
Operation Eenvironment
Indoor,Outdoor(Shelter)
Protection Level
IP45
Communication Interface
Standard RS485 interface, distance ≤1200 meters
Input Interface
Relay switch signal or 12V electrical level signal or 12V pulse signal of pulse width > 100ms, drive current >10mA



Edifice Entrance Access Control Turnstiles Full Height SS304 Acrylic BLDC Motor 1
