Face Recognition System Anti Crawling Sliding Glass Full Height Turnstile
PRODUCT DESCRIPTION
Optical sliding barrier is designed to control pedestrians entering or exiting restricted areas, usually used of
high pedestrian traffic flow in both directions.
The body is made from brushed stainless steel which creates a seamless and elegant access point to blend
into most indoor environment.
It can be integrated with any kind of access controller system (e.g.: RFID device, Push button, Fingerprint and
Biometric device).
In case of emergency, the barrier arm will open automatically to allow free passage. Optical sliding barrier are
suit for elegant and luxury entrance solutions.
MAIN FUNCTIONS & FEATURES
1. The whole system runs smoothly, long-life performance, high operation dependability and fast response.
2. Many options of working ways: Bi-direction card reading; One direction card reading and another no reading;
One direction card reading and another freely. And single direction photocell controlled passing and close.
Working ways can be set in the control panel.
3. When power off, barrier open automatically and power on again, barrier will close automatically.
4. When valid card read and passenger passed, arm can be delayed to close from 1-60s which can be set in
the control panel.
5. Automatic reset function. If the user fail to pass within the prescribed time (default time is 5 seconds), the system
will cancel the authority of the current user automatically.
6. If passenger pass without card read or valid card read, flap barrier will alarm untill passenger get back from
the Swing barrier and then take a valid card to be read for passing.
7. Swing barrier is with 485 interface for long-distrance control concern.
8. Anti-rush function: If there is no open single, arm will be holding tightly.
9. Double anti-clipping function: Photocell anti-clipping and mechanical anti-clipping. When passenger is going
through the Swing barrier, photocell will detect out this situation and will not close. After passenger passed, arm
will close automatically. During its reposition, if arm meets any obstacle, arm will get back automatcially or stop
working for a while with very slight force. Also it will alarm.
10. The barrier is with standard electrical interface for the integration of various readers and writers.
11. The barrier can count how many passenger has passed and will show it in the LED display(optional)
12. Direction display to guide passenger which direction is to go.
13. Card-reading with memory or without memory function.
PRODUCT PARAMETER
SPECS | |
Model
|
SN-SLB03
|
Brand | SINOMATIC from SHENZHEN CHINA |
Standard dimension
|
1200x330x1000mm
|
Framework Material
|
SS304
|
Material thickiness | 1.2mm at least |
Panel material
|
Acrylic
|
Material thickness | 10mm |
Passage Width
|
550mm(default)
|
Passing direction
|
Single directional/Bi-directional
|
Pass rate
|
30 person per minute
|
Operating time
|
0.2 seconds
|
Power input
|
AC100-240V,50/60HZ
|
Working voltage
|
24V
|
Working humidity
|
5%~95%
|
Working temperature
|
-25℃~+60℃
|
Working environment
|
Indoor/outdoor with tent
|
Communication interface
|
Dry contact
|
Mechanism
|
Brushless motor
|
Infrared sensor
|
4 pairs(default)
|
MCBF
|
5,000,000 Cycles
|
Application
|
Airports, Hotels, Governemnt Halls, etc
|
