168mm Column Clear Toughened Glass Swing Barrier Gate with Face Recognition
  • 168mm Column Clear Toughened Glass Swing Barrier Gate with Face Recognition
  • 168mm Column Clear Toughened Glass Swing Barrier Gate with Face Recognition
  • 168mm Column Clear Toughened Glass Swing Barrier Gate with Face Recognition
168mm Column Clear Toughened Glass Swing Barrier Gate with Face Recognition

168mm Column Clear Toughened Glass Swing Barrier Gate with Face Recognition

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-SW01
Product Details
Opening Transit Speed:
30-40 Persons Per Minute
Closing Transit Speed:
25-30 Persons Per Minute
Direction:
Single And Bi-directional
Motor:
Brushless DC Motor
Motor Voltage:
24V
Column Diameter:
168mm
Highlight:

Clear Toughened Glass Swing Turnstile

,

168mm Column Glass Swing Turnstile

,

120W Face Recognition Swing Turnstile

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T or western Union
Supply Ability
3,000pcs per month
Product Description
168mm Column Clear Toughened Glass Swing Turnstile Face Recognition
Stylish Stainless Steel Column 168mm Diameter Cylinder Swing Gate Recognition Systems
Application
The brush-less anti-collision swing barrier is an intelligent passage management equipment developed and produced by our company. It integrates exquisite mechanical transmission, microprocessor control, voice and various reading technologies. By configuring different reading equipment, the intelligent control and management of the passage can be completed. The machine can realize public channel access control and deterrence.
Technical Specifications
ITEM SPECIFICATION
Framework 304 Stainless Steel
Dimensions Column diameter: 168mm
Arm length 600-900mm
Dry Contact 12V
LED indicating light One
Card-reading window Supported
Rated power 120W
Operating temperature -25℃ ~ +60℃, RH ≤90%
Related humidity RH ≤90%
Communication Interface RS485, distance ≤1200m
Power supply AC 220V/110V ±10% 50/60MHZ (optional)
Opening Transit speed 30-40 persons per minute
Closing Transit speed 25-30 persons per minute
Our Advantages
  • Stylish stainless steel column and clear toughened glass wing present a bright, concise design
  • Bi-directional opening facilitates fast and safe access
  • Integration with recognition systems for user-friendly access control
  • High security and stability suitable for banks, corporate headquarters, airports and leisure venues
Product Photos
168mm Column Clear Toughened Glass Swing Barrier Gate with Face Recognition 0
Features
  • Working method can be set by buttons on the main panel
  • Anti-pinch and anti-collision protection with automatic motor stop and 2Kg force reset
  • Anti-illegal entry, anti-intrusion, and auto-close for reverse direction
  • Anti-collision with automatic gate closure when no valid signal is detected
  • Gate protection functions to prevent motor damage from external force collisions
  • Synchronized gate operation
  • Auto-reset function with adjustable timing (1-60s, default 10s)
  • Reset function by photocells (4 or 6 pairs)
  • Anti-pinch function by photocells (4 pairs)
  • Compatible with access control, consumption, ESD, and e-ticket systems
  • One-way or two-way control options
  • Remote control and administration capability
  • LED lamp indicator
Frequently Asked Questions
What time do you need to delivery?
Typically, 5-7 working days after payment for common orders, depending on order quantity. Delivery timelines are confirmed before final payment.
How about the payment method?
Standard products: 30% deposit, 70% balance payment before shipment.
Customized products: 50% deposit, 50% balance payment before shipment.
Contract amount over USD 15000: 50% deposit, 50% balance payment before shipment.
Payment methods: T/T, PayPal, Alibaba Credit guarantee order.
How to ship
Shipping by air or by sea. For quantities over 10 sets, sea freight is recommended to reduce costs.
