Passenger flow control brushless DC motor sliding metro turnstile with infrared photocell

Place of Origin SHENZHEN, CHINA
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-SLB02
Minimum Order Quantity 1
Price negotiable
Packaging Details CARTON/WOODEN
Delivery Time 5-10 working days after payment received
Payment Terms T/T or western Union
Supply Ability 1,000 pcs per month
Product Details
Temperature -20℃ To +60℃ Operating Voltage DC 24V
Power Supply Input 220V/110V ± 10% AC, 50 / 60Hz Power Consumption 30 Watt
Max Flow Rate 25 To 30 Person Per Minute Humidity 0 To 95%
High Light

electronic turnstiles

,

subway turnstile

Leave a Message
Product Description



Passenger flow control brushless DC motor sliding metro turnstile with infrared photocell



General introduction:



Full height sliding barrier is an innovative pedestrian control technology that designed to achieve best balance of quality, performance and affordability.



Full height sliding barrier provides a combination of reliable mechanical as well as electronic restriction for unauthorized visitor while still maintain a welcoming atmosphere. High door panel design prohibit attempt to climb over. Access control and time attendance reader can be integrated into sliding barrier.





Features:



1. Uses brushless DC motor eliminate the need of changing carbon brush thus reducing maintenance work. Key internal parts is treated with anti-rust and anti-septic to ensure long term reliability.


2. Sliding barrier design with high door panel to prevent unauthorized visitor from gaining access by climbing over or crawling under the gate.


3. Premium stainless steel and glass panel material with elegant arc design effectively help create an welcoming and elegant prestigious atmosphere at building entrance to impress your visitors.


4. High performance IR sensor is used to detect tail-gating, illegal passing attempt and pass through direction to ensure maximum security at front gate. Door panel will be closed if tailgating is detected.



5. During power failure, door panel will open automatically to allow free pass through.



Specifications of full height sliding gate:



Item

Specification

Motor type

Brushless DC motor

Access device input voltage

Dry contact or 12V electrical level signal

or > 100ms 12V impulse signal, driving current > 10mA

Motor voltage

DC 24V

Max flow rate

25 to 30 person per minute

Flap opening / closing time

1s

Reset time when power on

3s

Working temperature

-20°C~+60°C



Case of full height sliding gate:



Passenger flow control brushless DC motor sliding metro turnstile with infrared photocell 0
