DC24V 120W Automatic Sliding Garage Door Opener 1200N Remote And WIFI Control
  • DC24V 120W Automatic Sliding Garage Door Opener 1200N Remote And WIFI Control
  • DC24V 120W Automatic Sliding Garage Door Opener 1200N Remote And WIFI Control
  • DC24V 120W Automatic Sliding Garage Door Opener 1200N Remote And WIFI Control
DC24V 120W Automatic Sliding Garage Door Opener 1200N Remote And WIFI Control

DC24V 120W Automatic Sliding Garage Door Opener 1200N Remote And WIFI Control

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number PD1200
Product Details
Motor Power:
DC24V,120W
Open And Close Force:
1200N
Door Area:
18 Sq.m
Door Moving Speed:
16 Cm/sec
Limit Switch:
Electronic Limit Switch
Remote Control Range:
≥30 M
Highlight:

120W Automatic Sliding Garage Door Opener

,

DC24V Automatic Sliding Garage Door Opener

,

WIFI Control Sliding Garage Door Opener

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T, Western Union,
Supply Ability
3,000 pcs per month
Product Description
DC24V 120W Automatic Sliding Garage Door Opener
Professional automatic sliding garage door operator with 1200N force capacity, featuring remote and WiFi control capabilities for modern residential applications.
Product Features
  • Automatic safety reverse system for enhanced protection
  • Soft start and soft stop function for quiet operation
  • Auto-Close function for automatic door closure
  • Self-learning open and close obstruction force detection
  • Electronic limit adjustment for easy setup
  • Compatible with photo beams, extra receivers, and wall switches
  • Energy-efficient LED courtesy lighting
  • Optional battery backup available
  • Self-locking gear motors for secure operation
  • Low headroom design requiring only 30mm clearance
Technical Specifications
Warranty 1 Year
After-sale Service Online Technical Support, Free spare parts, Return and Replacement
Project Solution Capability Graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
Application Residential
Design Style Traditional
Place of Origin China
Brand Name SINOMATIC
Model Number PD
Type 800/1000/1200
Power Supply AC110V-AC220V
Motor Power DC24V/100W
Limit Setting Electronic
Drive Mechanism Chain / Belt
L.E.D Lighting 24V / 15pcs LED bulbs
Maximum Door Weight 80kg/100kg/130kg
Protection Level IP20
Important Safety Recommendations
  1. Please read carefully and adhere to all safety and installation recommendations.
  2. The opener is designed to meet local regulations. Installers must be familiar with applicable local requirements.
  3. Only qualified personnel with knowledge of occupational health and safety standards should perform installations.
  4. Improper installation may result in damage, injury, or liability for the installer.
  5. We strongly recommend including Photo Beam sensors for enhanced safety.
  6. Ensure the garage door is fully open and stationary before vehicle entry or exit.
  7. Verify the garage door is fully closed and stationary before leaving the premises.
  8. Keep hands and loose clothing away from the opener and garage door at all times.
  9. The Safety Obstruction System only works on stationary objects and may not detect moving obstacles.
  10. This appliance is not intended for use by persons with reduced capabilities without proper supervision.
SINOMATIC PD Series Automatic Sliding Garage Door Opener unit and components
Documentation
Download User Manual (PDF)
