Waist High AC220V Acrylic Arm Swing Barrier Gate SUS304
Place of Origin | Shenzhen, China. |
---|---|
Brand Name | SINOMATIC |
Certification | CE/ ISO |
Model Number | SN-SB01 |
Minimum Order Quantity | Sample order accepted |
Price | negotiable |
Packaging Details | Carton/Plywood box/Pallet |
Delivery Time | 5-10 working days after payment received |
Payment Terms | T/T or western Union |
Supply Ability | 3,000pcs per month |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMotor | BLDC Motor | Motor Voltage | DC24V |
---|---|---|---|
Framework Material | SUS304 | Arm Material | SUS304/Acrylic |
Application | Indoor/outdoor | Optional | Counter, Sensor |
High Light | AC220V Swing Barrier Gate,Acrylic Arm Swing Barrier Gate,SUS304 Pedestrian Swing Gate |
Automatic Pedestrian Waist High 304 Stainless Steel Security Swing Barrier Gate
PRODUCT DESCRIPTION
- SN-SB01 is the minimum optical swing barrier gate, single working, lower air freight cost for sample order,
with LED indicator for access, and optical swing can be extended according to project requirement.
- The swing barrier gate is an intelligent control device for the entrance and exit of the pedestrian passage.
- The swing barrier gate is a part of the entrance management system, combined with computer and access
control system, attendance system, ticketing system, which can realize various of functions for different scope.
Advantage of swing gate is the channel width can be extend easily, support motor bike bicycle and wheelchair pass.
OUR ADVANTAGES
The stylish stainless steel column and clear toughened glass wing present a bright and concise design.
Bi-directional opening facilitates fast and safe access. It can also be integrated with recognition systems
for user friendly access control.
Featured with high security and stability, it’s suitable for banks, corporate headquarters, airports and leisure
venues.
TECHNICAL SPECIFICATION
Brand
|
SINOMATIC |
Model
|
SN-SB01 |
Cabinet material
|
304 stainless steel
|
Barrier material
|
Stainless steel/Acrylic
|
Size
|
168*1050mm
|
Arm lenght
|
Max 800mm
|
Direction
|
Uni-direction or Bi-direction
|
Flow rate
|
30-40 person/min
|
Power supply
|
AC220V/110V,50/60Hz, DC24V
|
Working voltage
|
DC 24V
|
Operation Temperature
|
-15 °C - 70 °C
|
Operation Humidity
|
0 ~ 95% (No freeze)
|
Anti-panic mode
|
Auto open when power off
|
Communication
|
Dry contact, Relay signal, RS485
|
MAIN FUNCTION AND FEATURES
1. Stainless steel housing, rain-proof laser opening, novel and beautiful.
2. LINIX (the best micro-motor brand in China) brush-less DC motor is used and the surface is electroplated.
3. Length of arm: 500mm to 800mm.
4. Fault detection and alarm functions, easy to use and maintenance.
5. The running status can be programmed and controlled with the built-in keyboard on the main board.
6. Mechanical anti-pinch function. If the gate meets resistance in the reset process, motors will stop working
automatically within the prescribed time and reset again after the default delay (till fully reset).
7.Anti-breakthrough function. The gate is locked automatically until opening signal received.
8. Synchronization functions (for dual gate equipment).
9.Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds),
the system will cancel the authority of the current user automatically.
10. Gate can be set as normally open or normally closed.
11. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc. (Via dry contact signal)
12. Direction can be set as unidirectional or bidirectional.
13. The device can be connected to management computer to realize remote control and management.
14. LED direction indicator (optional)
15. Gate auto opens when power off and auto close when power on, complying with fire safety requirements.
16. Support infrared photocell for anti-pinch and reset function.
PRODUCT APPLICATION
The brush-less anti-collision swing barrier is an intelligent passage management equipment developed
and produced by our company. It integrates the exquisite mechanical transmission, microprocessor
control, voice and various reading and writing technologies. By configuring different reading and
writing equipment, the intelligent control and management of the passage can be completed. The
machine can realize the public channel's dissuade and access control
