Electric Parking Round Boom Barrier Gate Vehicle Access Control Security 3s High Speed
  • Electric Parking Round Boom Barrier Gate Vehicle Access Control Security 3s High Speed
  • Electric Parking Round Boom Barrier Gate Vehicle Access Control Security 3s High Speed
  • Electric Parking Round Boom Barrier Gate Vehicle Access Control Security 3s High Speed
Electric Parking Round Boom Barrier Gate Vehicle Access Control Security 3s High Speed

Electric Parking Round Boom Barrier Gate Vehicle Access Control Security 3s High Speed

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-KSBG-E1
Product Details
Opening/Closing Speed:
3s
Power Supply:
AC 220V, DC12V
Arm Type:
Round Arm
Arm Lenght:
2.5 Meter
Remote Code:
Rolling Code
Cabinet Color:
Red
Highlight:

Round Boom Barrier Gate

,

2.5 meter Boom Barrier Gate

,

Electric parking boom barrier

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
US$150
Packaging Details
Carton box
Delivery Time
5-7 working days after payment received
Payment Terms
T/T, Western Union, , D/A, L/C, D/P
Supply Ability
1,000 pcs per month
Product Description
Electric Parking Round Boom Barrier Gate - Vehicle Access Control Security
High-speed 3-second electric parking round boom barrier gate for secure vehicle access control. This automatic barrier system provides efficient and reliable security for parking facilities and restricted access areas.
Important Safety Notice
Automatic boom gates are designed for vehicle access control only and are not intended for pedestrian use.
Safety Precautions
  • Before installation, operation, or maintenance, always disconnect the power supply first
  • The product must be properly grounded with earth leakage protection on the power supply
  • Do not modify the original internal wiring
  • During power failure, switch off power supply first, then manually open the boom using the motor handle
  • Keep all control devices (push-buttons, remote controls) out of children's reach, installed at minimum 1.5m height
  • Only operate controls when you have clear visibility of the gate
  • Never open cabinet doors or covers while the machine is operating
  • Prevent children from playing on or around the gate
Technical Specifications
Specification Details
Place of Origin Shenzhen, China
Brand Name SINOMATIC
Model Number KSBG-E01
Power Supply DC 12-24V
Current ≤1A
Running Time ≤3S
Remote Control Code Rolling code supporting up to 100 remote controls
Working Temperature -20℃ to 60℃
Maximum Boom Length 2.5 meters
Remote Control Distance Less than 50 meters
Up/Down Time 3 seconds
Warranty One year
Application Central isolation barrier
Package Contents
  • 1 × Boom barrier machine
  • 1 × 2.5 meters barrier arm
  • 2 × Remote controls
  • 4 × M10×100 expansion bolts
Electric Parking Round Boom Barrier Gate Vehicle Access Control Security 3s High Speed 0
Installation Instructions
  1. Before installation, ensure there are no obstacles within 2.5 meters of the installation area
  2. Position the boom barrier on the ground and mark the locations for the 4 expansion bolts. Drill holes at the marked positions, insert the bolts, and fasten securely
  3. Assemble the 2.5-meter boom arm into the motor shell and tighten the bolts
  4. Connect the power cable and test the system using the remote control to verify normal operation
