IP54 DC Brushless Motor Telescopic Boom Traffic Barrier Gate
  • IP54 DC Brushless Motor Telescopic Boom Traffic Barrier Gate
  • IP54 DC Brushless Motor Telescopic Boom Traffic Barrier Gate
  • IP54 DC Brushless Motor Telescopic Boom Traffic Barrier Gate
IP54 DC Brushless Motor Telescopic Boom Traffic Barrier Gate

IP54 DC Brushless Motor Telescopic Boom Traffic Barrier Gate

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-DZE-BL
Product Details
Working Temperature(motor):
-35℃~ + 80℃
Power Supply Input Voltage:
AC100V~240V; DC24V
Boom Type:
Straight, Folding, Fencing
Duty Cycle:
100%
Motor Power:
200W MAX
Communication:
RS485, TCP/IP
Highlight:

Telescopic Boom Traffic Barrier Gate

,

IP54 Traffic Barrier Gate

,

Telescopic Boom Traffic Control Barrier Gate

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T, Western Union,
Supply Ability
3,000pcs per month
Product Description
IP54 DC Brushless Motor Telescopic Boom Traffic Barrier Gate
Advanced DC Brushless Motor Technology
High-performance telescopic boom barrier gate featuring advanced DC brushless motor technology for reliable traffic control applications.
Product Specifications
  • Working temperature (motor): -35℃ to +80℃
  • Power supply input voltage: AC110-120V or AC200-240V
  • Controller input voltage: DC24V±10%, 10A
  • Motor power: 200W MAX
  • Relative Humidity: 30% to 80%, No condensation
  • Remote control distance: ≥30M
  • Insulation grade: F
Optional Colors
IP54 DC Brushless Motor Telescopic Boom Traffic Barrier Gate 0
Boom Type and Speed Specifications
Boom Type Performance Specifications
Barrier Gate with Straight Boom
  • Boom length ≤3M, up speed 1.5S
  • Boom length ≤4M, up speed 3S
  • Boom length ≤4.5M, up speed 4S
  • Boom length ≤5M, up speed 5S
  • Boom length ≤5.5M, up speed 6S
Barrier Gate with Folding Boom
  • Boom length ≤3M, up speed 3S
  • Boom length ≤4M, up speed 4S
  • Boom length ≤5M, up speed 6S
Barrier Gate with Fence Boom
  • Two-levels, Boom length ≤3M, up speed 4S
  • Two-levels, Boom length ≤3.5M, up speed 5S
  • Two-levels, Boom length ≤4.5M, up speed 6S
  • Three-levels, Boom length ≤3M, up speed 5S
  • Three-levels, Boom length ≤4M, up speed 6S
Key Features & Functions
  • DC brushless motor with movable connecting rod transmission mechanism and balance spring for stable, reliable operation
  • Motor life cycle: ≥2,500,000 cycles
  • Spring life cycle: ≥500,000 cycles
  • Built-in delay auto-closing and obstacle detection with reverse function
  • Supports infrared photocell, loop detector, and external radar systems
  • Built-in DC12V power output
  • Standard 433MHZ learning code remote control for easy configuration
  • Battery backup capability with optional charging module
  • Universal mounting holes for articulated or fence boom configurations
Technical Specifications
Parameter Specification
Model SN-DZE-BL (speed 1.5-6s adjustable)
Running Speed 1.5s, 3s, 4s, 5s, 6s
Boom Types Straight, 90° folding, 180° folding, 2 fence, 3 fence
Max Boom Length 3m to 6m depending on configuration
Input Voltage AC 220V±10%, AC110V±10%, 50/60HZ
Motor Voltage DC24V
Enclosure Rating IP54
MTBF 2,500,000 cycles
Traffic Flow Application 1,500 cycles / 24 hours
Working Temperature -35°C to +85°C
Max Motor Power 200W
Max Motor Speed 24r/min
Frequently Asked Questions
Are you a Trade company or manufacturer for barrier gate?
We are a manufacturer and welcome factory visits. OEM products are available.
Why does the barrier boom sometimes open automatically?
Check the limit switch position and adjust if necessary. Refer to the Barrier Gate Manual or adjust the adjusting screw. Also verify spring intensity.
What is the remote control distance?
Most 418 remote controls cover up to 100 meters, but we recommend using within 30-50 meters for safe and stable operation.
Can the barrier gate be used outdoors in extreme weather?
Yes, the working temperature range is -40℃ to +75℃.
Is the installation direction changeable for the barrier gates?
Yes, our DC motor barrier gates can typically accommodate different installation directions.
