Double Direction Waist High Turnstile with Clear Acrylic Flap and Stainless Steel Housing
  • Double Direction Waist High Turnstile with Clear Acrylic Flap and Stainless Steel Housing
  • Double Direction Waist High Turnstile with Clear Acrylic Flap and Stainless Steel Housing
  • Double Direction Waist High Turnstile with Clear Acrylic Flap and Stainless Steel Housing

Double Direction Waist High Turnstile with Clear Acrylic Flap and Stainless Steel Housing

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-FB01
Product Details
Flap Material:
Clear Acrylic
Flap Color:
Clear Or Others
Power Supply:
110V/ 220V
Operational Voltage:
DC 24V
Prectection Level:
IP 44
Working Temperature:
-20℃ ~ +60℃
Highlight:

speedgate turnstile

,

pedestrian turnstile

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
3-10 working days after payment received
Payment Terms
T/T,Western Union,,D/P,D/A,L/C
Supply Ability
3,000pcs per month
Product Description
Double Direction Waist High Turnstiles - Clear Acrylic Automatic Flap Barrier
Advanced pedestrian flow control system featuring clear acrylic automatic flap barriers designed for efficient access management in industrial and commercial environments.
System Overview
This barrier system authorizes passage to individuals presenting valid electronic security credentials and seamlessly integrates with building access control infrastructure. The solution combines mechanical engineering, electronics, microprocessor technology, and multiple identification methods to deliver intelligent access control and management.
Core Functions & Features
  • Stainless steel housing with durable, stable mechanism and modern design
  • Compatible with access control, ticketing, ESD, consumption, and construction systems
  • Self-diagnostic functionality for simplified operation and maintenance
  • Configurable operational modes via built-in control panel menu
  • Multiple sensors detect obstructions during movement to prevent user injury
  • Anti-collision protection - flaps remain closed without open signal
  • Emergency power failure response with automatic flap opening
  • Fire alarm system integration for emergency situations
  • Automatic reset to closed position when power resumes
  • Automatic lock position when access time expires
  • Prevents invalid, tailgate, and wrong-direction access attempts
  • LED indicator lights (red/green) provide clear passage status
  • Compatible with diverse access control reader devices
  • Configurable for single or double pedestrian flow directions
Product Visualization
Double Direction Waist High Turnstile with Clear Acrylic Flap and Stainless Steel Housing 0
Technical Specifications
Product TypeAutomatic Speed Turnstile
Housing Material304 or 316 Stainless Steel
DimensionsL1200 x W300 x H1000mm
Wing Width270mm
Maximum Passage Width600mm
Power SupplyAC220V±10%, 50HZ / AC110V±10%, 60HZ
Motor VoltageDC24V
MCBF5 Million Cycles
Transit Speed30 Persons/Minute
Operating EnvironmentIndoor/Outdoor (Shelter Required)
Operating Temperature-20°C to +60°C
Customization Options
  • Housing material selection: 304 or 316 stainless steel
  • Housing length options: 1.2m, 1.4m, or 1.6m
  • Flap arm materials: acrylic glass, resin, PVC, and others
  • Flap arm colors: red, blue, yellow, colorless, and custom options
