Automatic Hydraulic Rising Bollard with No Drainage Required Weatherproof and Sealed Durable Construction
  • Automatic Hydraulic Rising Bollard with No Drainage Required Weatherproof and Sealed Durable Construction
  • Automatic Hydraulic Rising Bollard with No Drainage Required Weatherproof and Sealed Durable Construction
  • Automatic Hydraulic Rising Bollard with No Drainage Required Weatherproof and Sealed Durable Construction
Automatic Hydraulic Rising Bollard with No Drainage Required Weatherproof and Sealed Durable Construction

Automatic Hydraulic Rising Bollard with No Drainage Required Weatherproof and Sealed Durable Construction

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-S804M
Product Details
Waterproof:
IP68
Duty Cycle:
100%
Material:
Stainless Steel
Bollard Diameter:
219mm (273mm, 324mm Optional)
Color:
Black/Grey/Green/Red Etc
Warranty:
12 Months
Net Weight:
Approx. 53kg
Rising Height:
600mm
System Control:
Electric Hydraulic
Highlight:

No Drainage Required Bollard

,

Weatherproof and Sealed Bollard

,

Durable Construction Bollard

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
US$350~US$450
Packaging Details
Crate/Pallet
Delivery Time
5-7 working days after payment received
Payment Terms
T/T,Western Union,credit card/Cash/Alipay,L/C,D/A,D/P
Supply Ability
1,000 pcs per month
Product Description
Automatic Hydraulic Rising Bollard with No Drainage Required Weatherproof and Sealed Durable Construction
Advanced security bollards designed for school zones and industrial parks, featuring automatic retractable operation without requiring drainage systems.
Product Overview

A drainage-free automatic bollard is an automated security barrier that doesn't require a dedicated drainage system, eliminating the need for a connected storm drain. They achieve this by using weatherproof seals and robust, sealed internal mechanisms to protect against water ingress. This makes them simpler to install and suitable for a wider range of locations, especially those where drainage is difficult or impossible to install.

Key Advantages
  • No Drainage Required: Self-contained water-resistant design eliminates storm drain connections
  • Weatherproof Construction: High IP ratings (IP68) with protective seals against water, dust, and debris
  • Durable Materials: High-grade corrosion-resistant stainless steel with robust impact-resistant mechanisms
  • Simplified Installation: Hassle-free upgrade compared to traditional bollards requiring drainage pits
  • Reliable Operation: Sealed hydraulic cylinders or electric motors ensure smooth, quiet performance
Customization & Service Options
  • Multiple steel thickness options available (default 6mm)
  • Various color finishes to match your environment
  • Custom sizes tailored to specific requirements
  • OMRON PLC control system for steady, safe operation
  • Fast rising time with hydraulic pressure system
  • Durable stainless galvanization housing
  • Optimized frame structure with high anti-impact and loading capacity
  • Enhanced security with anti-collision capabilities
  • Reflective bands and low-energy LED lights for nighttime visibility
Technical Specifications
Specification Details
Bollard Color Stainless steel original color
Raising/Lowering Speed ≤4S / ≤2S
Diameter 219mm (168mm, 273mm, 324mm optional)
Rising Height 600mm default (800mm to 1000mm optiona)
Material SS304(SS316 optional)
Control Mode Remote control (≥50m)
System Control Hydraulic and electric control
Working Temperature -30℃～+75℃
Embedded Cylinder Depth 800mm
Lighting LED light (Acrylic light circle)
Power Supply 220V
Thickness 6mm(8mm/10mm/15mm/20mm optional)
Weight Approx. 53kg
Service Life At least 5 million cycles
Drainage Mode Natural drainage + External drainage system
Automatic Hydraulic Rising Bollard with No Drainage Required Weatherproof and Sealed Durable Construction 0
About SINOMATIC
Founded in 2002, SINOMATIC is a national high-tech enterprise specializing in research, development, production, and sales of intelligent access control products. With nearly 200 patented technologies, our product portfolio includes access control turnstiles, parking barrier gates, automatic gate openers, and anti-terrorism roadblocks suitable for government buildings, commercial plazas, residential areas, stations, and customs checkpoints.
Our strong innovation capabilities and advanced manufacturing processes position us as industry leaders in intelligent variable speed interconnection technology. SINOMATIC products are distributed globally through agency service outlets in over 150 countries and regions including the United States, Canada, UK, France, Germany, Russia, India, and throughout Asia, Middle East, and Africa.
Through superior product quality and comprehensive after-sales service, SINOMATIC has established itself as a world-renowned brand in access control solutions, committed to building trustworthy quality and representing Chinese manufacturing excellence worldwide.
