Boom Barrier Gate Vehicle Radar Detector 79Ghz High Detection Accuracy
Product Features
- Mobile APP debugging
- Advanced surge/shielding and protection functions
- Imported chips and imported raw materials
- Automotive grade components
- IP66 waterproof rating
- Suitable for all boom types
- No need to cut the road and bury the coil during installation
Product Function
This barrier gate control radar is specifically developed for entrance and exit management of parking lots and underground garages. It precisely controls the rising and falling of barrier booms by cooperating with the gate control system's main control board, effectively preventing accidental injury to vehicles or pedestrians in the radar field of view while enabling intelligent anti-smashing protection.
The radar utilizes a highly integrated RF chip SOC solution, featuring compact size, cost-effectiveness, all-weather operation capability, high detection sensitivity, precision, easy debugging and installation, along with exceptional stability and reliability.
Operating at 79GHz frequency with Linear Frequency Modulation and Continuous Waveform, the radar achieves up to 4GHz available bandwidth.
The MIMO array antenna design provides excellent angular resolution and high angle measuring accuracy.
This product accurately identifies and distinguishes pedestrians, vehicles, and other targets passing through the barrier boom area, preventing accidents such as "smashing the vehicle," "smashing the person," and "not dropping the barrier boom."
Product Advantages
- High detection accuracy with centimeter-level error
- Pedestrian detection capability to prevent accidents
- Driving direction determination
- High detection probability exceeding 99.9% for vehicles
- Flexible detection area configuration
- Expandable functions including differentiated models
- Target height measurement to reduce false scenarios
Convenience Features
Mobile APP debugging • Suitable for all boom types • No road cutting or coil burial required during installation
Product Specifications
| Place of Origin | China |
| Province | Guangdong |
| Brand Name | SINOMATIC |
| Product Name | 79Ghz Anti-smashing Radar |
| Connection Interface | RS485/Bluetooth |
| Technology | Millimeter Wave Radar |
| Working Frequency | 77~81GHz |
| Detection Scope | Up to 6 meters |
| Working Voltage | 10-16V |
| Description | Easy installation, Vehicle detection radar sensor |
| Operating Temperature | -40℃ to 85℃ |
| Average Power Consumption | < 2.5W |
| Waterproof Class | IP67 |
Main Features
LED Indicators: Two LED indicators on the radar surface - red LED indicates power status (stays on when powered), green LED indicates operating status (triggers when objects detected in access area).
Detection Zone Configuration: Default detection zone is 3 meters forward × 0.5 meters left/right sides. Different detection areas can be configured via mobile APP or debugging software.
Configuration Parameters: Detection area configurations are automatically saved and reloaded after power failure and restart.
Firmware Upgrade: Online firmware upgrades available through RS-485 or APP interface without removing cover board - new firmware activates after power restart.
Stable Performance: Millimeter wave radar sensing capability remains consistent under varying light conditions, weather (rain, fog, snow), and dust environments.
User Manual
Download User Manual (PDF)
