800KG Automatic Swing Gate Opener Residential Courtyard Keypad Alarm Lamp
  • 800KG Automatic Swing Gate Opener Residential Courtyard Keypad Alarm Lamp
  • 800KG Automatic Swing Gate Opener Residential Courtyard Keypad Alarm Lamp
  • 800KG Automatic Swing Gate Opener Residential Courtyard Keypad Alarm Lamp
800KG Automatic Swing Gate Opener Residential Courtyard Keypad Alarm Lamp

800KG Automatic Swing Gate Opener Residential Courtyard Keypad Alarm Lamp

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-PK400AC
Product Details
Max Single Leaf Lenght:
3 Meter/Leaf
Max Loading Weight:
400KG/Leaf
Limit Switch:
Mechanical
Power Supply :
220V,50Hz;110V,60Hz
Gate Moving Speed:
10 Second Per 90 Angle
Decoding / Frequency:
Rolling Code / 433.92MHz
Highlight:

800KG Automatic Swing Gate Opener

,

Courtyard Swing Gate Opener

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T, Western Union,
Supply Ability
2,000 pcs per month
Product Description
800KG Automatic Swing Gate Opener with Keypad, Alarm Lamp & Photo Sensor
The PK400AC swing gate opener is engineered for residential courtyard applications, supporting gate leaves up to 400kg in weight and 3.0 meters in width. This system delivers safe, reliable performance with comprehensive security features.
Product Highlights
  • Safe and reliable performance
  • Adjustable moving speed
  • Keypad and single button interface
  • Alarm lamp, photo beam & safety beam interface
  • User-selectable auto-close function
  • Integrated mechanical limit switches eliminate ground stops
  • Compatible with 2 openers or 1 opener with single control box
  • Available with articulated arm or sliding arm
  • Manual key release for emergency operation
Technical Specifications
Unit Model PK400AC
Power Supply 220V, 50Hz; 110V, 60Hz
Max. Gate Weight 400KG per Leaf
Max. Gate Length 3.0 m per Leaf
Motor Power 200W
Gate Moving Speed 10 seconds per 90° angle
Limit Switch Mechanical
Remote Control Capacity Up to 25 remotes
Decoding / Frequency Rolling code / 433.92MHz
Work Duty S2 15min
Noise Level ≤60dB
Operating Temperature -20°C to 70°C
Gross Weight 28KG (2 packages)
800KG Automatic Swing Gate Opener Residential Courtyard Keypad Alarm Lamp 0
Installation Guide
The PK400AC swing gate opener is designed for single leaf gates weighing less than 400kg, with gate length under 2.5 meters. The drive system utilizes worm and worm gear combined with pinion transmission. For protection, this gate opener must be installed inside the enclosure or yard.
Installation Preparation
Before installation, ensure the gate operates smoothly manually. Remove plastic covers from the main engine and mounting base plate, keeping all fasteners secure.
For electric lock installation, maintain 40-50mm clearance between gate bottom and ground. Without electric lock, ensure ≥20mm clearance.
Cable Requirements
Prepare appropriate fasteners, power cables (minimum 4 cores, 1.5mm² cross-section per engine), limit switch cables (minimum 3 cores, 0.75mm² cross-section per engine), and control box power cables (minimum 3 cores, 1.5mm² cross-section). Cable length should be determined based on installation site requirements.
Important: Position pipe outlets facing downward to prevent rainwater from entering along the cables.
Mounting Bracket Installation
For secure installation of PK400AC main engines, we recommend using expansion screws to fix the mounting brackets.
Download Complete User Manual (PDF)
