Outdoor Industrial Sliding Gate Opener 3000kgs Loading Capacity Heavy Duty
  • Outdoor Industrial Sliding Gate Opener 3000kgs Loading Capacity Heavy Duty
  • Outdoor Industrial Sliding Gate Opener 3000kgs Loading Capacity Heavy Duty
  • Outdoor Industrial Sliding Gate Opener 3000kgs Loading Capacity Heavy Duty
Outdoor Industrial Sliding Gate Opener 3000kgs Loading Capacity Heavy Duty

Outdoor Industrial Sliding Gate Opener 3000kgs Loading Capacity Heavy Duty

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-SL3000BP
Product Details
Max.gate Weight:
3000 Kg
Gross Weight:
53 KG With Carton Package
Recording Of Up Remotes:
400 PCS
Limit Switch:
Encoder
Control Mode:
Frequency Converter
Power Supply:
220V
Highlight:

3000kgs Industrial Sliding Gate Opener

,

Encoder Industrial Sliding Gate Opener

,

Frequency Inveter Door Operator Motor

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T, Western Union, , L/C, D/A, D/P
Supply Ability
1,00 pcs per month
Product Description
Outdoor Industrial Sliding Gate Opener - 3000kg Loading Capacity Heavy Duty
3000kg Loading Capacity Heavy Duty CE Certificate Outdoor Industrial Gate Opener Sliding Gate Door Operator Motor
Product Overview
The SL3000BP sliding gate opener is designed for gates weighing up to 3000kg. It features rack and gear transmission and must be installed inside an enclosure or yard for protection.
Technical Specifications
Unit Model SL3000BP
Power Supply 220V, 50Hz
Max. Gate Weight 3000KG
Motor Power 1500W
Control Unit Frequency Inverter
Gate Moving Speed 10 m/min
Limit Switch Encoder
Recording of up Remotes 400 pcs
Decoding / Frequency Rolling code / 433.92MHz
Work Duty S2 20min
Noise ≤60dB
Work Temperature -20°C~50°C
Gross Weight 53kg with carton package / 63kg with pallet
Main Functions and Features
  • Frequency inverter control unit
  • Keypad / single button interface
  • Alarm lamp, Photo beam & safety beam interface
  • User can select auto-close function
  • Auto-reverse when hitting obstacle during closing
  • Manual release design for emergency purposes
  • Thermal protection built in motor winding
  • Cover protection for the gear for enhanced safety
  • Turbine and worm drive setup for steady operation
  • Soft-start and slow-stop technology with auto-reverse function
  • Multiple interfaces (infrared, solar, Bluetooth, alarm lamp, camera, external buttons, etc.)
  • Easy assembly with manual operation capability during power failure
Outdoor Industrial Sliding Gate Opener 3000kgs Loading Capacity Heavy Duty 0
Outdoor Industrial Sliding Gate Opener 3000kgs Loading Capacity Heavy Duty 1
Installation Preparation
Ensure the sliding gate is correctly installed, the gate rail is horizontal, and the gate can be manually moved smoothly before installing the gate opener.
Cable Installation
To guarantee normal operation and protect cables from damage, bury the motor & power cable and controlling cable separately using two PVC tubes.
Concrete Pedestal Requirements
Precast a concrete pedestal of appropriate size to firmly install the gate opener. Verify the distance between the gate and gate opener is appropriate before casting the pedestal.
Important Safety Warnings
  • Before installing the main engine, ensure safety stop blocks are in place and functioning to prevent the gate from running out of the rail or safety range
  • Verify the main engine and components have good mechanical properties and the gate operates flexibly when manually moved
  • One control unit can only drive one main engine - using multiple engines will damage the control system
  • Do not install the product more than 5 cm above the ground
  • Earth leakage circuit breaker must be installed in a visible location with minimum mounting height of 1.5m to prevent access by children
  • After installation, check mechanical properties, gate movement flexibility after manual unlocking, and proper installation of infrared sensors (if applicable)
