Automatic Swing Barrier Gate Electronic Face Recognition Fast Lane Speed Turnstile Gate
  • Automatic Swing Barrier Gate Electronic Face Recognition Fast Lane Speed Turnstile Gate
  • Automatic Swing Barrier Gate Electronic Face Recognition Fast Lane Speed Turnstile Gate
  • Automatic Swing Barrier Gate Electronic Face Recognition Fast Lane Speed Turnstile Gate
  • Automatic Swing Barrier Gate Electronic Face Recognition Fast Lane Speed Turnstile Gate
Automatic Swing Barrier Gate Electronic Face Recognition Fast Lane Speed Turnstile Gate

Automatic Swing Barrier Gate Electronic Face Recognition Fast Lane Speed Turnstile Gate

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-HSG01
Product Details
Cabinet Material:
SS304
Motor Type:
BLDC Motor
Normal Running Life:
＞ 5 Million Times
Motor Voltage:
DC24V
Power Supply Brand:
MEAN WELL From TAIWAN
IP:
44
Highlight:

Automatic SS304 Swing Barrier Gate

,

DC24V Swing Barrier Gate

,

BLDC motor Speed Turnstile Gate

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T,Western Union,
Supply Ability
500 pcs per month
Product Description
Automatic Swing Barrier Gate with Electronic Face Recognition
The SINOMATIC BLDC motor fast speed gate provides reliable and efficient access control, ensuring only authorized personnel can enter designated building areas. This attractive turnstile solution handles high-volume traffic and demanding conditions with ease.
Key Features
  • Suitable for both indoor and outdoor installation
  • LED screen displays pass/stop indicators
  • Moderate level security protection
  • Configurable for one-directional or bi-directional operation
  • Optional magnetic card reader integration
  • 1.2mm stainless steel main body construction
  • Emergency release mechanism during power failures
  • Plexiglass door panels for custom signage
  • Shock absorption technology for smooth closing
  • Includes button unit and remote control accessories
  • Modular design for easy parts replacement
  • Operating voltage: 220V AC - 24V DC
Main Functions & Features
  • DC brushless motor rated for 5+ million passages
  • Multiple infrared detection sensors with anti-tailing tracking control
  • Customizable voice broadcast module
  • LED indicators for traffic direction and status
  • Anti-shock function with automatic door wing locking
  • Self-diagnostic system with audible/visual alarms
  • Automatic reset function with configurable timing
  • Flexible access status configuration
  • Memory mode for continuous fast traffic flow
Technical Specifications
Framework 304 Stainless Steel
Dimensions 1200 * 150 * 1000 mm
Dry Contact 12V
LED Indicating Light One
Card-reading Window Two
Rated Power 100W
Operating Temperature -25℃ to +60℃, RH ≤90%
Related Humidity ≥90% RH
Communication Interface RS485, distance ≤1200m
Power Supply AC 100V-240V, DC24V
Opening Transit Speed 35-40 persons per minute
Closing Transit Speed 30-35 persons per minute
Optional & Customized Functions
  • Alternative materials, finishes, and custom designs
  • LED counter functionality
  • Audio and visual alarms for invalid entries
  • Remote controlled button operation
  • Additional sensor transmitters and receivers
  • Infrared sensors reset function
  • Access control system integration
  • Camera system integration
  • Thermostat system integration
  • Flexible card reader mounting options
  • Stroboscopic alarm light for fast failure identification
Automatic Swing Barrier Gate Electronic Face Recognition Fast Lane Speed Turnstile Gate 0
Frequently Asked Questions
What is your product's biggest advantage?
DC Brushless Motor technology ensures maintenance-free operation, no attrition, low noise levels, and high intelligence capabilities.
What is your flap gates opening and closing time?
≤ 0.4 seconds
What is the Swing barrier gate working environment?
Suitable for both indoor and outdoor installations (with appropriate shelter).
Can I customize it?
Yes, we welcome OEM and custom orders as we are the manufacturer.
What's your warranty?
1-year comprehensive warranty coverage.
