370W AC Motor WIFI Remote Control Sliding Gate Operator PY800AC
  • 370W AC Motor WIFI Remote Control Sliding Gate Operator PY800AC
  • 370W AC Motor WIFI Remote Control Sliding Gate Operator PY800AC
370W AC Motor WIFI Remote Control Sliding Gate Operator PY800AC

370W AC Motor WIFI Remote Control Sliding Gate Operator PY800AC

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-PY800AC
Product Details
Motor:
AC Motor
Motor Power:
370W
Max.gate Weight:
800 KG
Gate Move Speed:
11~13m/min
Drive:
Gear Driven
Recording Of Up Remotes:
20 Pcs / 40pcs
Highlight:

Auto Reverse Sliding Gate Operator

,

Sliding Gate Operator 800 KG

,

Remote Control Slide Gate Operator

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T, Western Union,
Supply Ability
1,000 pcs per month
Product Description
PY800AC 370W AC Motor WIFI Remote Control Sliding Gate Operator
Professional-grade sliding gate operator with AC motor and built-in control unit, designed for commercial and industrial applications.
370W AC Motor WIFI Remote Control Sliding Gate Operator PY800AC 0
Key Features
  • AC motor with integrated control unit
  • Keypad and single button interface options
  • Alarm lamp, photo beam and safety beam interfaces
  • Configurable auto-close function
  • Soft start and slow stop operation (Smart version)
  • Automatic reverse when encountering obstacles during closing (Smart version)
  • Emergency manual key release mechanism
Applications & Performance
PY series gate openers are engineered for commercial and industrial use, capable of handling gate weights from 800kg to 2000kg with operating distances up to 12 meters (model dependent).
  • Oil lubrication system for extended durability
  • Heavy-duty construction with generous appearance
  • Compact, cost-effective design
  • Built-in control board or separate control box options
  • Spring or magnetic limit switch options
  • Complete installation accessory package
Technical Specifications
Model PY800AC
Power Supply 220V/50Hz; 110V/60Hz
Maximum Gate Weight 800KG
Motor Power 370W
Gate Moving Speed 11-13 m/min
Limit Switch Spring (mechanical) / magnetic
Remote Control Capacity 20 pcs / 40 pcs
Decoding / Frequency Rolling code / 433.92MHz
Work Duty S2 20min
Noise Level ≤58dB
Operating Temperature -20°C~70°C
Optional Accessories
  • Metal Gear Rack & Nylon Gear Rack (custom lengths available)
  • Photo beam sensor systems
  • Keypad access control systems
  • Push button controls
  • Warning light indicators
  • Solar panel systems (DC motor models only)
  • Backup battery units (DC motor models only)
Installation Guidelines
The PY800AC Sliding Gate Automation Kit is designed for gates up to 800kg in weight with maximum lengths of 12 meters. Gate motion is achieved through the rotating output gear driving the gear rack attached to the moving gate.
Important Safety Information: The opener must be installed within private property boundaries. All electrical work must be performed by a licensed electrician with power disconnected. The safety-interlocked operation requires pressing the remote once to open and again to close.
