AC110V 220V 400W Sliding Gate Opener Spring Mechanical / Magnetic Limit Switch

AC110V 220V 400W Motor Power Spring Mechanical Magnetic Limit Switch Intelligent Control Board Sliding Gate Operator

PRODUCT DESCRIPTIONS

* AC motor with built-in control unit.
* Keypad / single button interface.
* Alarm lamp, photo beam & safty beam interface.
* User can select auto-close function.
* Soft start and slow stop. (Smart version)
* Auto-reverse function when hitting obstacle during closing. (Smart version)
* Manual key release design for emergency purposes.

PRODUCT DISPLAY

FUNCTIONS AND FEATURES

* PY series gate opener designed for commercial and industrial use, weight from 800kg to 2000 Kg and operating distance up to 12 meters.(depends on the model )
* Oil lubrication, generous appearance, heavy duty.
* Compact structure, cost-effective.
* Built in control board or separately control box.
* Keypad / single button interface.
* Alarm lamp, Photo beam & safety beam interface.
* User can select auto-close function.
* Optional for spring limit switch and magnetic limit switch
* Manual key release design for emergency purposes.
* Automatic stop when hitting obstacle during opening, auto-reverse when hitting obstacle during closing. (Smart version)
* Installation accessories

TECHNICIAL SPECIFICATIONS

Optional Accessaries

• Metal Gear Rack & Nylon Gear Rack are optional, you can order the rack length accordig to your gate length;
• Photo beam sensor;
• Keypad systems;
• Push button;
• Warning light;
• Solar panel;
• Backup batteries;

INSTALLATION

Before You Start

*PY800AC/PY1000AC/PY1500AC/PY2000AC Sliding Gate Automation Kit is suitable for powering the opening and closing motion of gates up to 800, 1000, 1500, 2000kg in weight, up to a length of 12m.

*Gate motion is achieved by the rotating output gear of the gate opener driving the gear rack (sold separately) fitted to the moving gate.

*The gate opener requires you to press the remote control once to open, and once again to close. This is a safety feature to ensure safe operation.

*The opener must be fitted within private property, never externally to a property’s boundary.

Any works done to the gate opener must be completed whilst the power is off and the opener is unplugged. Any modifications/alterations/works to AC power components must only be completed by a licensed electrician.

FOR MORE DETAILS, PLEASE CLICK THE BELOW LINK TO DOWNLOAD THE USER MANUAL.

PY800AC, PY1000AC, PY1500AC, PY2000AC User Manual....
