Automatic Car Parking Lock Barrier IP67 Waterproof Battery Power Supply
  • Automatic Car Parking Lock Barrier IP67 Waterproof Battery Power Supply
  • Automatic Car Parking Lock Barrier IP67 Waterproof Battery Power Supply
  • Automatic Car Parking Lock Barrier IP67 Waterproof Battery Power Supply

Automatic Car Parking Lock Barrier IP67 Waterproof Battery Power Supply

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-BW-8
Product Details
Power Supply:
Lead Acid Battery Or Lithium Battery
Up Or Down Time:
5S~6S
Remote Distance:
≤30m
Down Height:
75mm
Rated Voltage:
DC6V
Rising Height:
390mm
Highlight:

390mm Car Parking Lock

,

Car Parking Lock IP67

,

Waterproof parking lock barrier

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
3-5 working days after payment received
Payment Terms
T/T, Western Union, , , L/C, D/A, D/P
Supply Ability
3,000 pcs per month
Product Description
Automatic Car Parking Lock Barrier IP67 Waterproof Battery Power Supply
Automatic IP67 Waterproof Lead Acid Battery or Lithium Battery Power Supply Car Parking Lock Barrier
This newly developed parking lock features a high-class varnished case with glossy finish. Designed with practical structure and user-friendly operation, it offers diversified functions with safe and durable performance. Ideal for car parking management in high-end residences, shopping malls, hotels, airports, and other commercial establishments.
Product Specifications
TypeAutomatic
Place of OriginShenzhen, China
Brand NameSINOMATIC or Customized LOGO
Model NumberSN-BW-8
Warranty12 months
Loading Capacity5 tons
NameIntelligent Parking Lock
Rated VoltageDC 6V
Quiescent Current≤1mA
Operating Current≤1.2A
Lifting Time≤4s
Rise Height390mm
Lower Height75mm
Control Distance≤15m
Working Temperature-10℃~+80℃
Dimension (Arm down)440*430*75mm
Gross Weight7 Kg
Automatic Car Parking Lock Barrier IP67 Waterproof Battery Power Supply 0
Key Features & Functions
180° Anti-Collision Protection
Features flexible design with self-protection function. The parking lock rotates back and forth to protect against external collisions while activating an alarm.
Heavy Duty & Durable Construction
High-quality steel housing supports up to 5 tons weight. Spray plastic coating provides waterproof, rustproof, and dustproof protection for long-lasting performance in harsh weather conditions. Steel rolling sway arm maintains shape even when compressed by vehicles.
Rechargeable Battery with Extended Runtime
Powered by rechargeable battery providing approximately 3 months of continuous use after charging. Includes recharging power pack. Optional built-in solar panel minimizes charging requirements.
Low Battery Alarm System
Automatic alarm activates when battery power is low, alerting users to recharge.
Additional Functions & Features:
  • Original 180° two-way rocker design
  • Effective damage prevention when parking vehicles
  • Indicator light flashes when power is low
  • Automatic alarm and descent when impacted by vehicles
  • High-quality DC motor
  • Excellent airtight design with superior waterproof function (IP67 rated)
  • Rechargeable DC 6V battery provides approximately 3 months continuous use
  • Remote control operation for automatic barrier rising when leaving parking space
  • Strong compressive resistance up to 3 tons
  • 12-month warranty included
Installation Instructions
  1. Grab the parking lock rocker by hand, then use the key to open the lock and lift the cover for installation.
  2. Based on the three mounting holes on the parking lock foot, drill three holes with 12mm diameter and 50mm depth, then install M8 expansion bolts.
  3. Place the parking lock base holes over the expansion bolts, install and tighten nuts to complete installation.
  4. For use: Open the top cover, insert the battery plug into the parking lock socket, and place the battery flat.
  5. Replace the cover by fitting the upper and lower fixing blockers of the box (cover the upper cover and push forward), then lock the upper cover.
