Dry Battery Rechargeable Parking Lock App Control 390mm Rising DC6V
  • Dry Battery Rechargeable Parking Lock App Control 390mm Rising DC6V
  • Dry Battery Rechargeable Parking Lock App Control 390mm Rising DC6V
  • Dry Battery Rechargeable Parking Lock App Control 390mm Rising DC6V

Dry Battery Rechargeable Parking Lock App Control 390mm Rising DC6V

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-BW-8
Product Details
Color:
Black/yellow
Running Time:
5S
Remote Distance:
≤50m
Down Height:
60mm
Rated Voltage:
DC6V
Rising Height:
390mm
Highlight:

Dry Battery Rechargeable Parking Lock

,

390mm Rising Rechargeable Parking Lock

,

DC6V Parking Space Lock

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
3-5 working days after payment received
Payment Terms
T/T, Western Union, , , L/C, D/A, D/P
Supply Ability
3,000 pcs per month
Product Description
Dry Battery Rechargeable Parking Lock with App Control
Automatic intelligent parking lock with smartphone app control, featuring a rechargeable battery system. This motorized parking barrier automatically lifts with remote control operation and includes built-in anti-collision protection. Designed with a simple, elegant appearance, it offers dustproof and waterproof construction, easy operation, long service life, and reliable security performance. Ideal for managing dedicated parking spaces in high-end residential complexes, commercial buildings, hotels, and institutional facilities.
Product Specifications
TypeAutomatic Parking Lock
Place of OriginChina, Guangdong Province
Brand NameSINOMATIC
Model NumberSN-BW-8
Warranty12 months
Loading Capacity3 tons
Rated VoltageDC 6V
Quiescent Current≤1mA
Operating Current≤1.2A
Lifting Time≤4s
Rise Height390mm
Lower Height75mm
Control Distance≤15m
Working Temperature-10℃~+80℃
Dimension (Arm down)440*430*75mm
Gross Weight7 Kg
Dry Battery Rechargeable Parking Lock App Control 390mm Rising DC6V 0
Product Advantages
180° Anti-Collision Protection
Features flexible design with self-protection capability. The parking lock can rotate back and forth to prevent damage from external collisions while simultaneously activating an audible alarm.
Heavy Duty and Durable Construction
Housing constructed from high-quality steel rolling capable of supporting up to 5 tons. Spray plastic coating provides waterproof, rustproof, and dustproof protection for long-term performance in harsh weather conditions. The steel rolling sway arm maintains structural integrity even when subjected to vehicle pressure.
Rechargeable Battery with Extended Operation
Powered by rechargeable battery system that provides approximately 3 months of continuous use per charge. Includes recharging power pack. Optional solar panel integration minimizes charging requirements.
Low Battery Alarm System
Integrated alarm system alerts users when battery levels are low, reminding owners to recharge the unit.
Functions & Features
  • Original 180° two-way rocker design
  • Effective protection against vehicle damage during parking
  • Indicator light flashes when power levels are low
  • Automatic alarm and lowering function when impacted by vehicles
  • High-quality DC motor for reliable operation
  • Excellent airtight design with superior waterproof functionality
  • Rechargeable DC 6V battery provides approximately 3 months of continuous use
  • Remote control operation for convenient parking space management
  • Strong compressive resistance up to 3 tons
  • 12-month comprehensive warranty
Installation Instructions
  1. Grab the parking lock rocker by hand, then use the key to open the lock and lift the cover for installation
  2. Drill three holes with 12mm diameter and 50mm depth according to mounting hole locations on the parking lock foot, then install M8 expansion bolts
  3. Place the parking lock base holes over the expansion bolts, install and tighten nuts to complete installation
  4. For operation, open the top cover and insert the battery plug into the parking lock socket, then position the battery flat
  5. Replace the cover by fitting upper and lower fixing blockers (cover the upper cover and push forward) and lock the upper cover
