10mm Acrylic Arm Speed Lane Turnstile Anti Tailgating ARM control

10mm Acrylic Arm Max 1 Meter Passage Width 100% Duty Cycle Speed Lane Turnstile

OUR ADVANTAGES

1. Adopt Brush-less motor,it has less mechanical wear and ensure a longer lifescircle.
2. Adopt ARM control technology, merits for stronger function and better expand-ability.
3. Modular design, the structure is more simple and easier for your installment and maintenance.
4. Anti-collision design, turnstile mechanism will be pretected to lessen after-sale maintenance rate;
5. Anti -tailgating function is optional.
7. Higher cost effective( Good performance and affordable price)

BASIC SPECIFICATIONS

1. Size: 1200*150*980mm
2. Material: 1.5mm SUS 304 Hairline 400#+Top Cover black marble
3. Arm material: 10mm Acrylic
4. Pass Width: Standard 600mm max 900mm
5. Arm Height: 800mm to 1500mm(depends on arm lenght)
6. Passage direction Single directional/Bi-directional
7. Pass rate: 30-35 persons/minute
8. Operating time: 0.2 seconds
9. Power input: AC100-240V,50/60HZ
10. Working voltage: 24V
11. Working humidity: 30%~95%
12. Working temperature: -40℃~+70℃
13. Working environment: Indoor
14. Input interface: RS485, Dry contact
15. Mechanism: DC Brushless motor 120W
16. Infrared sensor: 4 pairs
17. MCBF: 5,000,000 Cycles
18. Application: Office Building, Hotels, Government Halls, etc

PRODUCT FEATURES

1. The device adopts DC brush-less motor, which supports at least 5 million normal passages.

2. The device adopts multiple pairs of infrared detection sensors, and adopts anti-tailing tracking control technology,

which can be passed by authorized personnel. When unauthorized personnel enter, an audible and visual alarm will

be issued.

3. The device integrates a voice module which can customize the voice broadcast content according to user

requirements.

4. The device uses LED to indicate the traffic direction and display the traffic status.

5. The device has anti-shock function. When there is intrusion, the door wing is automatically locked.

6. The equipment has self-test, self-diagnosis, automatic alarm function, sound and light alarm function including

illegal intrusion alarm, reverse intrusion alarm, trailing alarm etc.

7. The device has an automatic reset function. When the gate does not pass within the specified time after opening

the door, the system will automatically cancel the user's permission for the current pass and set the transit time.

8. The device supports flexible configuration of the access status (controlled, free traffic, no traffic) in the inbound

and outbound directions.

9. The device supports the memory mode which enables continuous and fast traffic.

HIGH SPEED GATE APPLICATION

Intelligent high speed gate ---can be compatible with IC card, ID card, barcode card, fingerprint reading card

recognition device used for staff, provide civilized, orderly access methods; effectively manage the access of

staff. Can be widely used in the station, wharf subway, factories, office building, hotel, clubs, intelligent

community, enterprises and institution that need intelligent access management.

TECHNICIAL SPECIFICATIONS

FAQ

1. What is your products biggest advantage?
-------- DC Brushless Motor , no maintenance all the of life, No Attrition, Low Noise ,Hight Intelligence.


2. What is  your flap gates opening and closing time ?
-------- <=0.4s .

3. What is the Swing barrier gate Working environment ?
-------- They can be used indoor and outdoor(with shelter)

4. Can I customize it ?
-------- Yes, Welcome . We are the manufacturer , We are welcome OEM .

5. What's you warranty?
-------- 1 year time warranty .
