SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed
  • SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed
  • SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed
  • SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed
  • SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed
  • SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed
  • SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed
  • SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed
SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed

SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-HRB01
Product Details
Material:
SS304
Diameter:
219mm
Height:
600mm
Thickness:
6mm
Up Time:
3s To 6s Adjustable
Down Time:
3s To 6s Adjustable
Min. Loading:
100T
Weight:
150KG±
Power:
300W Integrated
Working Temperature:
-65℃~+75℃
Highlight:

automatic retractable bollards

,

automatic driveway bollards

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-7 working days after payment received
Payment Terms
T/T,Western Union,,credit card/Cash/wechat
Supply Ability
1000 pcs a month
Product Description
Anti Rust Retractable Integrated Rising Bollards Customization Lifting Column Surface
Advanced customization lifting column surface anti-rust retractable rising bollards manufactured in China. This high-quality automatic bollard provides superior protection for security areas against vehicle intrusion.
Product Introduction
This automatic bollard is designed for high-security entrance protection, featuring a rapid 3-second raising time. Engineered to withstand high-speed impacts from heavy vehicles, the bollard's solid construction ensures it remains operational even when vehicles sustain damage upon collision.
Key Advantages
  • Integrated LED bar for enhanced nighttime visibility and accident prevention
  • Manual lowering capability during power outages
  • PLC (Programmable Logic Controller) compatibility for flexible control options including biometric readers, remote control, and push buttons
Applications
Ideal for customs, ports, prisons, military bases, and other high-security facilities requiring reliable traffic guidance and protection of people and property.
SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed 0
Product Specifications
Product Name Electro-hydraulic integration rising bollards (Cylinder)
Model No. SN-HRB01
Power Supply 220V
Operating Temperature -35℃ ~ +75℃
Power 1.5KW/2.2KW/3.7KW
Protection Level ≥IP68
Storage Environment -10℃~65℃, Rainproof, moisture proof and dustproof
Diameter ≥219mm
Material 304 stainless steel
Application Government agencies, Schools, Apartment Block Access
SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed 1
Functions & Features
  • Anti-collision: Operational after impact from 12-ton vehicles
  • Anti-destructive power: Deforms after impact from 16-ton vehicles
  • Internal structure: Load-bearing steel beam and column, anti-collision steel beam column, 4 navigation rods
  • Manual lowering capability during power outages
  • Linkage interface compatibility
  • Reversible operation during ascent and descent
  • Operating noise ≤60 dB
  • Waterproof integrated hydraulic drive system
  • 24V control solenoid valve
  • Adjustable control box display text (up, down, start, time control)
  • English language display
  • Water immersion performance: No leakage during 48 hours with normal lifting capability
Product Details
SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed 2
Crash Test Performance
SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed 3
Case References
SS304 Automatic Rising Bollard with 100T Loading Capacity and 3s-6s Adjustable Speed 4
Troubleshooting Guide
Control Box Always Trips
The wiring may be damaged or affected by moisture. Check the wiring promptly to identify and resolve the issue.
Remote Control Failure
If wireless remote control fails but manual buttons work, first replace remote batteries. If problem persists, the receiver may be faulty - contact us for replacement.
Bollards Lowering Automatically When Rising
This may indicate issues with the mechanism or pressure maintaining valve. Check hydraulic oil levels and add if necessary. If fault continues, contact us for mechanism or valve replacement.
LED Light Malfunction
If all LEDs are off, check wiring connections. If only one LED is malfunctioning, the LED strip may need replacement.
Bollards Cannot Fully Raise or Lower
After extended non-use, dust and sand may accumulate inside, causing slow operation. Clean the bollard mechanism to restore full functionality.
