LED Direction Guide Optical Turnstile Gate With Wheel Mechanism

Place of Origin Shenzhen, China.
Certification CE/ ISO
Model Number SN-TT
Minimum Order Quantity Sample order accepted
Price negotiable
Packaging Details Carton/Plywood box/Pallet
Delivery Time 7 working days after payment received
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 2,000 pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Motor DC 24V Brush Motor Power Consumption 50W
IP Level IP44 Warranty 1 Year
Package Carton Box Voltage AC220V/110V
High Light

IP44 Vertical Tripod Turnstile


Wheel Mechanism Optical Turnstile Gate


LED Direction Optical Turnstile Gate

Leave a Message
Product Description


Digital LED direction guide optical turnstile gate with special wheel mechanism


Features of Tripod Turnstile Gate Motor:


1.Special wheel mechanism is used here to realize the function of fixing and also unfixing all the parts of the turnstile

2.All the system runs stable with little noise and no mechanical impact

3.It can self-check and alarm which will be make it convenient to use

4.Several ways of working molds can be chosen at your request

5.It can work bi-direction, or one direction permitted, one forbidden, or one direction charged, one for free, and all the working molds can be set by the buttons in the main control board

6.Beam falling and lifting can be controlled in far distance so to satisfy the special requirement of the users and the request of fire protection

7.Beam can be lifted and fall when electricity is cut-off

8.It has the standard electrical interface which can be connected with various kinds of reader and writer equipment

9.So all the functions can be realized in one integration machine and can be controlled and managed by the computer in the far distance

10.The number of the persons who have passed by can be counted automatically which can also be displayed in LED

11.Direction-guide lights are in the turnstile to tell you which direction can go or which cannot

12.You can set the function with or without card-reading memory according to your requirement

13.The number of the persons who can pass by the turnstile can be set to meet the requirement of some special occasions

14.After reading the card, if the person who punched the card does not pass it within the set time, then this chance to access will be canceled, and the set time can be changed according to your request.


Arms auto drop down when power off:


LED Direction Guide Optical Turnstile Gate With Wheel Mechanism 0


Arms auto rise when power on:

LED Direction Guide Optical Turnstile Gate With Wheel Mechanism 1


Specifications of Tripod Turnstile Gate Motor:


Type Automatic
Max load-bearing of pole 80KG
Power supply
AC220±10%V 50Hz/AC110±10% 60Hz
Power consumption
Access device input voltage
Dry contact or 12V electrical level signal or > 100ms 12V impulse signal, driving current > 10mA
Max flow rate
30 to 40person per minute
Arm length
Working temperature
Control circuit
Working humidity
IP level



More photos:

LED Direction Guide Optical Turnstile Gate With Wheel Mechanism 2

Standard housing for this motor:

LED Direction Guide Optical Turnstile Gate With Wheel Mechanism 3

Return and Warranty:


Our company products are guaranteed for one year, from date of sale providing free maintenance based on not being damaged by any man-made.


♦ During the warranty period, all faults caused by the product itself can be maintained for free.



♦ Within the period of free maintenance, faults or damages caused by mane-made or natural disasters can be maintained with additional charge.


♦ Over the period of free maintenance, faults or damages can be maintained with additional charge.


The following conditions are not under warranty:


♦ Damages caused by abnormal operation, man-made or natural disasters;
