100W 50HZ Access Control Turnstile Gate 10mm Acrylic Indoor DC Motor
  • 100W 50HZ Access Control Turnstile Gate 10mm Acrylic Indoor DC Motor
  • 100W 50HZ Access Control Turnstile Gate 10mm Acrylic Indoor DC Motor
  • 100W 50HZ Access Control Turnstile Gate 10mm Acrylic Indoor DC Motor

100W 50HZ Access Control Turnstile Gate 10mm Acrylic Indoor DC Motor

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-HSG01
Product Details
Frame Material:
SS304, Acrylic
Passing Rate:
30~40 Person/minute
Barrier Material:
Acrylic (color Optional)
Motor Type:
BLDC Motor
Packing Material:
Plywood Box
Normal Running Life:
> 5 Million Times
High Light:

100W Access Control Turnstile Gate

,

50HZ Access Control Turnstile Gate

,

10mm Acrylic Swing Turnstile Gate

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
500 pcs per month
Product Description

Indoor Type DC Driving Motor Access Control Recognition Turnstile Gate



PRODUCT DESCRIPTION



Speed Gate series are intelligent passage management equipment researched, developed and produced by

our company. The equipment is integrated with delicate mechanical transmission, microprocessor control, and

various read/write techniques. It can be used for intelligent control and management of the passage after

equipped with different read/write devices.


The outline of the product is formed after pressing the stainless steel plate. The shape is featured as pleasing

appearance, good looking,stainless and durable. The system is provided with a standard electric interface and

is easily integrated into the equipment with read/write facilities such as magnetic card, bar code card, ID card

and IC card. As a result, an orderly and civilized passage is provided for the personnel in and out, and illegal

personnel can be barred. At the same time, a special fire control interface is equipped in the system to meet

the requirement of fire control passage, so that a rapid down rod control may be realized in emergency for

diverting passengers.





PRODUCT SPECIFICATIONS



Model
SN-HSG01
Size
1200x150x1000mm
Unlock time 0.2s
Arm material
10mm Acrylic
Passage Width
500mm ~900mm
Pass rate
30-40 persons/minute
Power input
AC100-240V,50/60HZ
Working humidity
30%~95%
Working temperature
-40℃~+70℃
Working environment
Indoor/outdoor with shelter
Communication interface
RS485, Dry contact
Infrared sensor
4 pairs (default)
MCBF
5,000,000 Cycles
Power consumption 100W



KEY FEATURES


1.Both Indoor and Outdoor
2.Led Screen Pass or Stop Sign
3.Moderate Level Security
4.One-directional or Bi-directional
5.Magnetic Card reader (optional)
6.Main body manufactured 1,2 mm stainless steel
7.In case of electric failures or cuts, the system pulls the wings in, releasing and unlocking the main mechanism
8.Plexi door panels suitable for signs ( STOP/ DISABLED)
9.Moderated with shock absorption while closing
10.Accessories Buton Unit and Remote Control
11.Modular design to ensure easy parts replacement
12.Operating Voltage : 220V AC- 24V DC



MAIN FUNCTION AND FEATURES



1. The device adopts DC brush-less motor, which supports at least 5 million normal passages.



2. The device adopts multiple pairs of infrared detection sensors, and adopts anti-tailing tracking control technology,

which can be passed by authorized personnel. When unauthorized personnel enter, an audible and visual alarm will

be issued.


3. The device integrates a voice module which can customize the voice broadcast content according to user

requirements.


4. The device uses LED to indicate the traffic direction and display the traffic status.


5. The device has anti-shock function. When there is intrusion, the door wing is automatically locked.


6. The equipment has self-test, self-diagnosis, automatic alarm function, sound and light alarm function including

illegal intrusion alarm, reverse intrusion alarm, trailing alarm etc.


7. The device has an automatic reset function. When the gate does not pass within the specified time after opening

the door, the system will automatically cancel the user's permission for the current pass and set the transit time.


8. The device supports flexible configuration of the access status (controlled, free traffic, no traffic) in the inbound

and outbound directions.


9. The device supports the memory mode which enables continuous and fast traffic.





FAQ



1.What is your products biggest advantage?
-------- DC Brushless Motor , no maintenance all the of life, No Attrition, Low Noise ,Hight Intelligence.


2.What is  your flap gates opening and closing time ?
-------- <=0.4s .


3.What is the Swing barrier gate Working environment ?
-------- They can be used indoor and outdoor(with shelter)


4. Can I customize it ?
--------Yes, Welcome . We are the manufacturer , We are welcome OEM .


5.What's you warranty?
-------- 1 year time warranty .
