BLDC Motor SS304 Entrance Retractable Barrier Gate IP54 DC24V
  • BLDC Motor SS304 Entrance Retractable Barrier Gate IP54 DC24V
  • BLDC Motor SS304 Entrance Retractable Barrier Gate IP54 DC24V
  • BLDC Motor SS304 Entrance Retractable Barrier Gate IP54 DC24V

BLDC Motor SS304 Entrance Retractable Barrier Gate IP54 DC24V

Place of Origin Shenzhen, China.
Certification CE/ ISO
Model Number SN-FB02
Product Details
Max Flow Rate:
30 Person Per Minute
Control Signal:
Relay/dry Contact Signal
IP Grade:
Motor Type:
BLDC Motor
Wooden Box
High Light:

SS304 Entrance Retractable Barrier Gate


BLDC Motor Retractable Barrier Gate


DC24V Turnstile Flap Barrier

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T or western Union
Supply Ability
3,000pcs per month
Product Description

304 Stainless Steel Entrance Automatic And Manual Fast Speed Retractable Barrier Gate


Working principle of flap barrier


The working principle of the flap barrier: a fast retractable door is embedded in each of the two wings of the

passage. When the device detects the opening signal, the two doors will be synchronized and quickly

retracted to make the current passage in a barrier-free state. The main control panel of the machine has

pulse signal instructions, the control system directs the work of the mechanical system, and the gate is opened.


When the pedestrian passes the sensing point, the machine control board informs the movement of the electric

switch. Illegal intrusion into the machine alarms, there are electronic anti-pinch and mechanical anti-pinch, the g

ate opens and closes in place to become a dead point mechanism, and pedestrians cannot be opened, which

improves the reliability of traffic.


Adaptation range of wing gate


It is suitable for one-way or two-way control of the flow of people entrance and exit channels.

  • Import and export channels of stations, docks, and tourist attractions
  • Ticket inspection channels such as exhibitions and swimming pools
  • Import and export attendance, access control and consumption management of communities, factories,
  • Enterprises and institutions
  • Special channel control





Material 304 stainless steel
Working voltage AC100V~240V
Drive motor DC24V DC brushless motor
size 1200*280*980
Flap length 270MM
Channel width 550 to 600MM
Fire interface provide relay fire linkage interface
Voice prompt support
direction Single/bi-direction
Working temperature -20℃~70℃
Humidity ≤90%( No condensation)
Working Environment Indoor / Outdoor (Shelter)
Gate opening and closing time 0.6 seconds
Passing speed

40 people / minute (normally open)

25-30 people / minute (normally closed)

Power-on time The time required to enter the passage state after power-on is 3s.
Service Life 5 million cycles
Communication interface standard RS485/232 dual serial port interface, distance ≤1200 meters
Input interface relay switch signal or 12V level signal or 12V pulse signal with pulse width >100ms, drive current >10mA




1.With fault self-test and alarm prompt function, convenient for user maintenance and use.


2.Through the built-in small push-pull on the main control board, device operating state can be programed.


3.The mechanical structure has anti-pinch and anti-collision function. When the swing arm is blocked during

the reset process, the motor automatically stops working within the specified time. Reset again after the default

delay (until reset), and the force is very small (≤ 2kg).(In the extreme case, all infrared rays are disabled, and

the movement still has mechanical anti-pinch function, and the strength is small and will not cause harm to

the human body)


4. Illegal intrusion, trailing alarm, reverse intrusion gate automatically closes


5.Anti-shock function, the arm is automatically locked when no open signal is received.


6.Telescopic arms are adjustable synchronously (for double pendulum)


7.With automatic reset function. After the switch is opened, the system will automatically cancel the user's

permission for the pass when there is no pass within the specified time.The reset time is adjustable from 1s

to 60s (the system default time is 10s). After the power is cut off, the channel is automatically opened

(in accordance with fire protection requirements), and the power-on channel is automatically closed.


8.Infrared sensor reset, infrared sensor anti-trap function (configure 5 pairs of infrared)


9.It can be connected with a variety of devices such as access control systems, consumer systems, electronic

ticket systems, biometric systems, and electrostatic testers.


10.The one-way or two-way control personnel can enter and exit, and the infrared sensing in and out channels.


11.Voice prompt function.


12.Remote control and management can be achieved directly through the management computer.
