Stainless Steel 90 Degree Half Height Turnstile 30W 0.2S
  • Stainless Steel 90 Degree Half Height Turnstile 30W 0.2S
  • Stainless Steel 90 Degree Half Height Turnstile 30W 0.2S

Stainless Steel 90 Degree Half Height Turnstile 30W 0.2S

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-HHT01
Product Details
Thickness Of Frame:
1.2mm At Least
Arm Lenght:
About 450mm To 500mm
Material:
SUS304
Control Circuit:
24V
Control Signal:
Relay Switch Signal
Pass Speed:
30 Person/minute
High Light:

Stainless Steel Half Height Turnstile

,

90 Degree Half Height Turnstile

,

0.2S Access Control Pedestrian Turnstile

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-7working days after payment received for sample
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
3,000pcs per month
Product Description

Access Control Stainless Steel Security Machinery 90 Degree Half Height Pedestrian Turnstile



Product description



Waist height rotor turnstile, the whole profile is stamped from the standard SS304, beautiful and generous shape,

rust proof, durable, resisting external damage.The passageway composed of rectangular frame and barrier arm

can provide orderly and civilized access for the pedestrians, prevent illegal access. The product adopt the most

advanced drive control technology, which can be meet the various requirements of different modern buildings

styles for intelligent access control systems by changing the design range widely.



The turnstile designed for the pedestrians automatic access, with the highly perfect system, has the extensive

usability, convenient for compating IC card, ID card, bar code dimension code, fingerprint, ID card and other

card readert identification equipment, to achieve the access intelligent control and management.



This waist-height turnstiles designs with tailored stainless steel make its elegance-looking,durable and anti-oxidation .Considering unique requests,we built-in standard electrical interface to best-fit customer easier using magnetic card,barcode,ID&IC cards integrated .

This system provides civilized,well-organized pass management .



Main function and features



1.The whole system runs smoothly, long-life performance, high operation dependability and fast response.


2.The mechanism is equipped with an automatic regulated hydraulic buffer device. No noise and impact when running.


3.Self-test function, when power on, system restoration automatic.


4.Dual-bearing device, keeping the gate in balance when there is external force.


5.Single directional or Bi-directional is selectable.


6.LED indicator supported


7.Automatic reset function: when Full Height Turnstile receives an open single, but passenger do not pass through

the hallway within a specific time (default 5s), turnstile arm will lock automatically. Limit passing time (01-60 seconds),

passing time can be set on Full Height Turnstile circuit board.


8.When power off, turnstile lane will be free to pass, complying with fire safety requirements.



9. The rotary wings will be locked automatically if the system do not receive IR signal



10. Multi-passage for variety application demands ,Cover 99% needs on earth



11. Programmable signal separate control : pass time,pass speed etc. parameters



12. RS232/RS485 interface meet all kind of communications or WIRELESS connection



13. Compatible IC/ID card ,flexible couple



14. Long-distance management through COMPUTER



15. Customize Options: LED display,Voice guide ,Warning Lamps,Indicator Lights guide, Audible &Visible Alarm



Waist height turnstile  specifications



Product name
Waist Height Turnstile
Place of Origin
Shenzhen, Guangdong, China
Brand name
SINOMATIC
Model Number
SN-HHT01
Material
SS304
  Product process   CNC Laser Cutting
MCBF
5 million cycles
Power supply
AC100V~240V
Pass direction
Bi-directional
Pass speed
30 persons/min
Size
1400*300*1000mm
Color
Silver
Card-reading window
reserved
Working environment
Indoor/Outdoor
Working Temperature
-20℃~60℃
Working Humidity
5%~95%



Technical Parameters

Input voltage 100V~240V
Driving voltage 24V
Equipment power 30W
Response time 0.2S
Passing speed 30 people / min
Communication distance less than 1200m
Open signal input dry contact
Switching door time Less than 1S





Stainless Steel 90 Degree Half Height Turnstile 30W 0.2S 0
