SUS304 0.2S Full Height Barrier Gate Fingerprint Recognition
  • SUS304 0.2S Full Height Barrier Gate Fingerprint Recognition
  • SUS304 0.2S Full Height Barrier Gate Fingerprint Recognition
  • SUS304 0.2S Full Height Barrier Gate Fingerprint Recognition

SUS304 0.2S Full Height Barrier Gate Fingerprint Recognition

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-FHT02
Product Details
Material:
Standard SUS304
Response Time:
0.2S
Package:
Woodne Case
Arm Angle:
90 Or 120 Degree
Input Interface:
Dry Contact
Power Supply:
100v-240v
High Light:

SUS304 Full Height Barrier Gate

,

0.2S Full Height Barrier Gate

,

Fingerprint Recognition Full Body Turnstile

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
3,00pcs per month
Product Description

Security Entrance Electronic Fingerprint Recognition Control Used Full Height Turnstile Gate



Product Introduction



The full high turnstile is designed to provide unsupervised access control for office or building.



The impenetrable construction eliminates any unauthorized access to restricted areas.

To gain authorized passage through the turnstile, the user must present a valid card for the access control system.

Upon presentation of the valid card. the turnstile will unlock to allow the user to pass through the direction requested.



The turnstile can also work with push button, fingerprint and face recognition access control system.



Product Application



Suitable for commercial buildings, subways, airports, customs, exhibition halls, government buildings, financial

institutions, clubs and other high-end indoor applications.



Product Advantage Feature



1. Running stable without noise and mechanical impact

2. Equipped with the dry contact signal input interface, compatible with all kinds of access controllers.

3. After swiping card in normal condition, if within the permitting time passages do not pass, the system willcancel

the users’ pass right and arm close automatically

4. Arm automatically open when the power off to make sure safety In case of emergency

5. Optional for external counter to record the people numbers for each lane

6. Single way or Bi-directional adjustable based on the requirement

7. Equipped with LED directional indication / status lights









PRODUCT SPECIFICATION



Dimension

Single-channel:1500*1350*2300mm

Dual-channel:2400*1500*2300mm

Stainless Steel Specification Body: SS304

Passage width

About 600mm
Power Supply AC110V±10V,60Hz / AC220V±10V,50Hz
Drive motor DC24V solenoid
Passing Speed

30 persons/min

Input Interface +12V electrical signal or DC impulse signal with width >100ms
Communication Interface relay signal
Operating Temperature -20°C ~ 60°C
Related Humility <=95%
Package Wooden Box



MAIN FUNCTION AND FEATURES



1) Automatically low noise mechanism core equipped, highly cost-performance



2) Sense positioning, reducing mechanical impact make lifetime longer



3) Operating efficiency, 1~2 seconds open & close



4) Lowest Noise : No matter in operating or outside control, Noise control under 30db



5) Self-checking and Alarm warning for maintainence



6) Resetting: System cancel authorized pass if passenger delayed pass



7) Anti-following : prevent illegal passing



8) Anti-clamp :The wings will stopped during in external block, the wings reset again after default delay



9) The rotary wings will be locked automatically if the system do not receive IR signal



10) Multi-passage for variety application demands , cover 99% needs on earth



11) Programmable signal separate control : pass time,pass speed etc. parameter



12) RS232/RS485 interface meet all kind of communications or wireless connection



13) Compatible with IC/ID card reader, fingerprint reader, face recognition devices.



14) Long-distance management through COMPUTER



15) Customize Options: LED display, Voice guide, Warning Lamps, Indicator Lights guide, Audible &Visible Alarm



Basic parameters:

ITEM SPECIFICATIONS
Dimensions 2300*1370*2300mm
Cabinet material 38 round tube, 1.2mm Mild steel or SS304/316
Channel width 600mm
Ambient temperature -20 degrees to 60 degrees
Working environment indoor and outdoor (outdoor canopy)



Technical Parameters:

Input voltage 100V~240V
Driving voltage 24V
Equipment power 40W
Response time 0.2S
Passing speed 30 people / min
Communication distance Less than 1200m
Open brake signal input Dry contact
Switching door time Less than 1S
