Remote Control Turnstile Entrance Gates , Single Arm 304 Stainless Steel Turnstile

China Remote Control Turnstile Entrance Gates , Single Arm 304 Stainless Steel Turnstile supplier

Large Image :  Remote Control Turnstile Entrance Gates , Single Arm 304 Stainless Steel Turnstile

Product Details:

Place of Origin: SHENZHEN, CHINA
Brand Name: SINOMATIC
Certification: CE/ ISO
Model Number: SN-SB02

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Packaging Details: CARTON/WOODEN
Delivery Time: 5-10 working days after payment received
Payment Terms: T/T or western Union
Supply Ability: 3,000pcs per month
Contact Now
Detailed Product Description
Access Device Input Voltage: Dry Contact Or 12V Electrical Level Signal Arm Opening / Closing Time: 1S
Waranty: 1 Year Direction: Single Or Double ( Can Be Set)
Drive Motor: DC 24V Power Supply: AC220±10%V 50Hz/AC110±10% 60Hz

304 stainless steel OEM/ODM remote control automatic single arm  turnstile with infrared sensors



Introduction of single arm turnstile:



Sinomatic single arm turnstile realizes the intelligent control and management for the passageway by matching all kinds of identity recognition system equipments and adopting the reliable performance of the security protection devices, alarm devices, direction indicators and so on.



Applications of  single arm turnstile:



Sinomatic single arm turnstile gate is mainly applied in the metro station, wharf, subway station, bus station, factories, office building , hotel, clubs, school, library, supermarket and institution that need intelligent access management.



Features of  single arm turnstile:

  • Fault detection and alarm functions, easy to use and maintenance.
  • The running status can be programmed and controlled with the built-in keyboard on the main board.
  • Mechanical antipinch function. If the gate meets resistance in the reset process, motors will stop working automatically within the prescribed time and reset again later.
  • Anti-breakthrough function. The gate is locked automatically until opening signal received.
  • Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically.
  • Gate can be set as normally open or normally closed.
  • Can be used with variety of access control devices: IC / ID card readers, bar codes, fingerprints, etc. (Access controller needed).
  • Direction can be set as single-direction or bi-direction.
  • Gate auto opens when power off and auto close when power on, complying with fire safety requirements.
  • Alarm function, in case of illegal intrusion and reverse intrusion, etc.



Specifications of  single arm turnstile:



Item

Specification

Power supply

AC220±10%V 50Hz/AC110±10% 60Hz

Access device input voltage

Dry contact or 12V electrical level signal

or > 100ms 12V impulse signal, driving current > 10mA

Motor voltage

DC 24V (brush motor)

Max flow rate

25 to 30 person per minute

Flap opening / closing time

1s

Reset time when power on

3s

Working temperature

-20°C~60°C



Cases of  single arm turnstile:



Remote Control Turnstile Entrance Gates , Single Arm 304 Stainless Steel Turnstile



Why choose us:



1. Our Factory has 13 years OEM/ODM experiences in the line of access control turnstile and barrier.
2. Prompt delivery time. Usually we keep stock of standard model which ensure the prompt delivery.
3. We accept OEM/ODM orders to meet the requirements of clients.
4. Trial order is acceptable. Clients can buy sample order and test it before bulk order.

5. Online technical support makes it carefree to be our business partner.

6. A variety of transportation for your choice. Sea shipment, air cargo or express, depends on your demand.

7. Factory can be visited on working days. Clients are warmly welcome to visit our factory.
