168mm Column Clear Toughened Glass Swing Turnstile Face Recognition
  • 168mm Column Clear Toughened Glass Swing Turnstile Face Recognition
  • 168mm Column Clear Toughened Glass Swing Turnstile Face Recognition
  • 168mm Column Clear Toughened Glass Swing Turnstile Face Recognition

168mm Column Clear Toughened Glass Swing Turnstile Face Recognition

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-SB01
Product Details
Opening Transit Speed:
30-40 Persons Per Minute
Closing Transit Speed:
25-30 Persons Per Minute
Direction:
Single And Bi-directional
Motor:
Brushless DC Motor
Motor Voltage:
24V
Column Diameter:
168mm
High Light:

Clear Toughened Glass Swing Turnstile

,

168mm Column Glass Swing Turnstile

,

120W Face Recognition Swing Turnstile

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-10 working days after payment received
Payment Terms
T/T or western Union
Supply Ability
3,000pcs per month
Product Description

Stylish Stainless Steel Column 168mm Diameter Cylinder Swing Gate Recognition Systems



Application


The brush-less anti-collision swing barrier is an intelligent passage management equipment developed
and produced by our company. It integrates the exquisite mechanical transmission, microprocessor
control, voice and various reading and writing technologies. By configuring different reading and
writing equipment, the intelligent control and management of the passage can be completed. The
machine can realize the public channel's dissuade and access control



Technical Specifications



ITEM SPECIFICATION
Framework
304 Stainless Steel
Dimensions
Colunm diameter:168mm
Arm length
600-900mm
Dry Contact
12V
LED indicating light
One
Card-reading window
supported
Rated power
120W
Operating temperature
-25℃ ~ +60℃, RH ≤90%
Related humidity
RH ≤90%
Comunication Interface
RS485,distance ≤1200m
Power supply
AC 220V/110V ±10% 50/60MHZ (optional)
OpeningTransit speed:
30-40 persons per minute
Closing Transit speed:
25-30 persons per minute



Our advantage:



The stylish stainless steel column and clear toughened glass wing present a bright and concise design.



Bi-directional opening facilitates fast and safe access. It can also be integrated with recognition systems for user friendly access control.



Featured with high security and stability, it’s suitable for banks, corporate headquarters, airports and leisure venues.



Product photos:

168mm Column Clear Toughened Glass Swing Turnstile Face Recognition 0



Features:



1. working method can be set by the buttons on the main panel


2. Anti-pinch, anti-collision. If there is block during return of gate, motor stops working automatically. Reset again after a default delay, the force 2Kg.


3.Anti-illegal in, anti-intrusion, auto close for reverse direction.


4. Anti-collision, gate closes when no valid signal is given.


5. Protection functions for gate, gate open to prevent motor from being damaged if there is outer force collision.


6. Gates can be synchronous


7.Auto-reset. If not go through in a preset time, pass right would be cancelled automatically. (1-60s adjustable), default time is 10s.


8. Reset function by photocells, 4 or 6 pairs.


9. Anti-pinch function by photocells, 4 pairs


10.Compatible with Access control system, consumption system, ESD system, E-ticket system and so on.


11. One way or two way control


12. Unit can be controlled and administered by remote control


13. Led lamp indicator



FAQ

What time do you need to delivery?
Commonly to say, 5-7 working days after payment coulddelivery for common orders, but it depends the order quantity. We could talk about this question before final payment.


How about the payment method?
Standard products: 30% deposit, 70% balance payment before shipment.
Customized products: 50% deposit, 50% balance payment before shipment.
Contract amount more than USD15000: 50% deposit, 50% balance payment before shipment.
T/T, PayPal, Alibaba Credit guarantee order


How to ship
By air or by sea, quantity over 10 sets better to choose by sea to reduce cost.
