Home ProductsTripod Turnstile Gate

Indoor 35persons/min 0.2S SS304 3 Arm Tripod Turnstile

Indoor 35persons/min 0.2S SS304 3 Arm Tripod Turnstile

    • Indoor 35persons/min 0.2S SS304 3 Arm Tripod Turnstile
    • Indoor 35persons/min 0.2S SS304 3 Arm Tripod Turnstile
  • Indoor 35persons/min 0.2S SS304 3 Arm Tripod Turnstile

    Product Details:

    Place of Origin: SHENZHEN, CHINA
    Brand Name: SINOMATIC
    Certification: CE/ ISO
    Model Number: SN-TT03

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: negotiable
    Packaging Details: CARTON/WOODEN
    Delivery Time: 5-10 working days after payment received
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 1,000pcs per month
    Contact Now
    Detailed Product Description
    Material: GB 304 Stainless Steel Size: 1200*280*980mm
    Material Thickness: 1.2mm Bi-direction: Default
    Package: Plywood Open Signal: Dry Contact
    High Light:

    SS304 3 Arm Tripod Turnstile

    ,

    0.2S 3 Arm Tripod Turnstile

    ,

    35persons/Min Tripod Barrier Gate

    No Noisy Shockproof 304 Stainless Steel 3 arm turnstile mechanism



    PRODUCT INTRODUCTION



    A turnstile, also called a barrier gate or turnstile, is a form of gate which allows one person to pass at a time. It can also be made so as to enforce one-way traffic of people, and in addition, it can restrict passage only to people who insert a coin, a ticket, a pass, or similar. Thus a turnstile can be used in the case of paid access (sometimes called a faregate or ticket barrier when used for this purpose), for example to access public transport, a pay toilet, or to restrict access to authorized people, for example in the lobby of an office building.



    Dimensions
    1200 x 280 x 980mm (Size Customization Acceptable)



    PRODUCT FUNCTIONS

    1.Auto replacement function, reposition after person pass by

    2.Anti tail function auto-lock once turn 120° .

    3.Arms auto drop when power off , insure unblocked when accident

    4.Standard electronic interface, remote control through internet which is also could connect variety card readers and receive relay signal to work

    5.Diverse control mode optional, changeable due to varying, convenient for your manage

    6.Auto alert error function, comfort for user maintain and operate

    7.Manual button or remote control ,Bio-directional passage

    8.Open signal with memory or with out set function

    9.Red and green light to show pass or stop, leisure to exit and entrance





    Specifications of Tripod Turnstile Gate



    Model
    SN-TT03
    Size
    1200*280*980mm
    Material
    1.2mm SS304
    Pass Width
    550mm
    Passage direction
    Bi-directional
    Pass rate
    30-35 persons/minute
    Operating time
    0.2 seconds
    Power input
    AC100-240V,50/60HZ
    Working voltage
    24V
    Working humidity
    5%~95%
    Working temperature
    -40℃~+70℃
    Working environment
    Indoor/outdoor
    Communication interface
    12v Dry contact, Relay










    PRODUCT DIMENSION

    Indoor 35persons/min 0.2S SS304 3 Arm Tripod Turnstile 0





    Packaging Details


    Commodity: Tripod Turnstile Barrier
    Package Type: Export Wooden Box
    Product Dimension: L1200 * W280 * H990mm
    Packing Dimension: L1300 * W400 * H1160mm
    Unit Weight: 60kg
    Gross Weight: 80kg
    CBM: 0.60CBM/pcs
    Port: Shenzhen Yantian, Shekou
    Lead Time : 3-7days



    Safety and User-Orientated Design



    • Drop arm design for emergency purpose

    • There are no exposed screws, it is safer for the user.

    • Smooth operation designed for mas transit application

    • The pictogram on the device indicating access permission and direction of movement

    • Special designed case shape, it is user-friendly for passenger to punch card or finger.

    • Anti-tailgate



    Easy Integration



    • Flexible reader installation plate. Customer can easily integrate third party reader.

    • Standard electrical interface for third party device.

    • Using compact mechanism, the turnstile has more space inside for integration

    • We provides integration service in factory, with board and peripherals installed, ensuring compliance of the system. When the turnstile is delivered, just and plug in and do the setting. Save the cost of installation.

    • The two columns at the ends provide more space for system integration
