60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power
  • 60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power
  • 60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power
  • 60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power
  • 60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power
  • 60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power
  • 60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power
  • 60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power

60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-HRB01
Product Details
Bollard Material:
SS304
Diameter:
219mm(default), 273mm, 324mm
Height:
600mm(default), 800mm 1000mm
Thickness:
6mm(default), 8mm,10mm, 12mm
Up Time:
3s To 6s Adjustable
Down Time:
3s To 6s Adjustable
Min. Loading:
80T
Weight:
150KG±
Power:
300W Integrated
Working Temperature:
-65℃~+75℃
High Light:

automatic retractable bollards

,

automatic driveway bollards

Payment & Shipping Terms
Minimum Order Quantity
Sample order accepted
Price
negotiable
Packaging Details
Carton/Plywood box/Pallet
Delivery Time
5-7 working days after payment received
Payment Terms
T/T, Western Union, MoneyGram, credit card/Cash/wechat
Supply Ability
1000 pcs a month
Product Description

60 dB low noise 304 stainless steel 3.7KW system dynamic power automatic driveway bollards



DESCRIPTION



Hydraulic automatic bollard usually integrate of oil pump unit and steel frame construction. It use soil

pressure as dynamic to realize the rise/fall of bollard.As a moving device, it is usually installed at vehicle

entrance/exit. It rises to block the vehicle and falls to the ground level to authorize free passing.







PRODUCT PARAMETERS



System Control electric hydraulic Raised Height (Mm) 600mm(customized available)
Material 304 staineless steel or A3 steel with painting Bollard Dia (Mm) 168,219,273 mm
Color customized Thickness (Mm) 6 mm (Customized)
Power Supply 380V(control voltage 24V) Weight (Kg) + 180 kg
System Dynamic Power (W) 3.7Kw Led Light extra charge
Casing Size L500 *W500 *H900/L600 *W600 * H900 Full Set Includes bollard, control box



















































60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power 0







60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power 1



FUNCTIONS & FEATURES



1. Anti-collision:It can be used normally after being hit by a 12-ton vehicle.

2. Anti-destructive power:After being hit by a 16-ton vehicle, Hydraulic road bollards deformation.

3. internal structure:With load-bearing steel beam and column, anti-collision steel beam column,

    4 navigation rods

4. Can be manually lowered in the event of a power outage

5. Linkage interface

6. Reversible operation according to requirements during ascent and descent

7. Noise during operation of the device≤60 dB

8. Waterproof integrated hydraulic drive

9. Control solenoid valve 24V

10. Control box display text adjustable (up, down, start, time control adjustment)

11. Display text in English

12. Water immersion performance:no leakage during 48 hours and normal lifting

13. Anti-corrosion performance level: 9



60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power 2



PRODUCT DETAILS



1. Automatically raise/lower/stop.The automated bollards adopt a heavy duty hydraulic power pack and

    operate by integrated control.Easy to install and operate. Built-in led flashing lights and reflective tap

    in the bollard head to ensure visibility and safety.

2. Variable frequency controller. Adopt variable frequency controller,the raise/lower speed 3-6s is adjustable.

    It can stop emergently during raising/lowering process. The control signal is electric transmission, quick and reliable.

3. Firm foundation plate.Thicken seamless 304 stainless steel with strong bearing capacity more than 40 tons.

    Rust protection and distortion resistance.

4. Built-in valve.In case of emergent issue for example power failure, the obstacle can be lowered by relief valve

    manually to make sure the passage of pedestrians and vehicles in not affected.

5. Adopt high quality great power motor, the bollards can raise/lower speedy,work stable and durable with 1500

    cycles working frequency per day.The motor can be disassembled for easy maintenance.

6. Multiple security protection.Use high pressure air rifle to seal up the vent,the motor can work when soaked

    in water with electricity leakage protector.



CASE REFERENCE



60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power 3



INSTALLATION



60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power 4

60dB Low Noise Automatic Rising Bollards 304 Stainless Steel 3.7KW System Dynamic Power 5





APPLICATIONS



Scientific and educational units: schools, computer rooms, research centers, libraries, etc.;

Leisure and entertainment venues: parks, scenic spots, pedestrian streets, municipal squares, playgrounds, etc..

Traffic: bus station, railway station, subway station, airport, etc..

Business service places: hospitals, banks, hotels, clubs, commercial buildings, etc..

Office space: large office buildings, public inspection units, hydro power and oil and gas units etc.
