    Product Details:

    Place of Origin: SHENZHEN, CHINA
    Brand Name: SINOMATIC
    Certification: CE/ ISO
    Model Number: SN-HRB02

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: negotiable
    Packaging Details: CARTON/WOODEN
    Delivery Time: 5-7 working days after payment received
    Payment Terms: T/T, Western Union, MoneyGram, L/C, D/A, D/P
    Supply Ability: 100 pcs per month
    Contact Now
    Detailed Product Description
    Housing Lenght: 3m To 6m Blocking Length: 2.7m To 5.7m
    System Power: 3.7KW Min. Loading: 80 Tons
    Lifting Height: 500mm(default) Material Thickness: 16mm(default)/20mm/25mm
    Power Supply: 380V Control Voltage: 24V
    Service Lift: 5 Million Times

    Anti-terrorist 3 phases 380V power input Electric Automatic LED light hydraulic security barriers

    GENERAL DESCRIPTION


    Road blockers are designed especially for entrance points which have a threat of vehicle attack or for the ones that

    have high security requirements. To control the vehicle access in high security application and traffic control system,

    hydraulic road blockers are the unique solution and the most secure equipment. Even though the attack is from high

    tonnage vehicles with high speeds, it's not possible for the vehicle to keep on moving because of the damage given

    to front, wheels , rims and the bottom of the vehicle.


    Automatic road blockers provide a highly secure method of protecting a roadway against vehicular entry, offering an

    extremely overt visual deterrent which matches it’s ability to stop any road vehicles attempting to gain unauthorized

    access to your site. It can be widely used for high security applications such as custom house, border, port wharf,

    airport, prison, nuclear plant, military sites, government office building, high industrial risk factory and other sensitive places.






    PRODUCT PARAMETERS


    Product Name Hydraulic Road Blocker
    Model No. SN-HRB02
    System Control Electro-hydraulic
    Material Q235 carbon steel (A3 steel)
    Panel Thickness 16mm(default)
    Operating Temperature -35℃~75℃
    Protection Level IP68
    System Dynamic Power 3.7-5.5KW
    Intercepting Height 500mm
    Size L3000*W1000*H760mm(default)





    PRODUCT DISPLAY


    Wireless Remote Control LED Light Hydraulic Security Barriers 3 Phases 380V Power Input



    OPTIONAL COLOR

    Wireless Remote Control LED Light Hydraulic Security Barriers 3 Phases 380V Power Input

    COMPONENTS

    Wireless Remote Control LED Light Hydraulic Security Barriers 3 Phases 380V Power Input

    FEATURES & FUNCTIONS


    1. System: hydraulic
    2. Voltage: 3 phase 380V(control voltage DC24V)
    3. Rising time: 1S to 3S (adjustable)
    4. Working temperature: -35℃ to 75℃
    5. Material: A3 steel, spay anti-rust paint
    6. Weight: ± 1.2Tons
    7. The road blocker has a buffer function
    8. LED light color: red, blue, green, yellow, purple, white etc.(total 20 colors are available)
    9. In case of power outage, the blocker can be manually raised and lowered.
    10. Remote control distance: 50 to 100mm (depends on the environment)
    11. Device running noise: ≤60 decibel
    12. Control solenoid valve :24v



    PRODUCTION PHOTO

    Wireless Remote Control LED Light Hydraulic Security Barriers 3 Phases 380V Power Input

    Wireless Remote Control LED Light Hydraulic Security Barriers 3 Phases 380V Power Input

    OPTIONS


    1. Access control and systems
    2. Emergency buttons with lock down
    3. UPS backup for the electrical system
    4. STOP / NO Entry warning signs
    5. Accumulator systems for hydraulic operation in power failure conditions
    6. Inductive loop systems
    7. Traffic lights and back-indications systems

    CASE REFERCE
     Wireless Remote Control LED Light Hydraulic Security Barriers 3 Phases 380V Power Input




    Wireless Remote Control LED Light Hydraulic Security Barriers 3 Phases 380V Power Input

    ABOUT OUR COMPANY


    Sinomatic Technology is located in Shenzhen, China.Our manufacturing plant with approx. 4.700

    square meter space, is equipped with modern production lines, own powder coating facility, developing

    department, processing center.

    Products are widely used in transportation road, schools, government agencies, airports, prisons, military,

    customs, border control, parks,smart city and other fields.



    Our aim is to use our knowledge, experience, manufacturing and design capacity, to be able to offer more

    flexibility than other manufacturers, providing custom made solutions, within short lead time and with value

    for money. Very resistant and durable products for reasonable pricing, variety of customization and system

    integration options, are the focuses for our business. With excell performance in overseas market, our products

    are exported to Europe, US,East Asia, Russia, the Middle East Islamic war countries etc.


    Advanced technology is accompanied by highest international quality standard. Comprehensive design,

    outstanding high technological standards together with superb corrosion protection, we gain trust of customers

    all over the world. At the same we keep competitive price policy. Fast and dynamic growth of our company in recent

    years and we're becoming better and better.
