Smart DC Brushless Motor Turnstile Access Control System For Security Control

Place of Origin Shenzhen, China.
Brand Name SINOMATIC
Certification CE/ ISO
Model Number SN-SLB03
Minimum Order Quantity Sample order accepted
Price negotiable
Packaging Details Carton/Plywood box/Pallet
Delivery Time 5-10 working days after payment received
Payment Terms T/T or western Union
Supply Ability 1,000 pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Wing Panel 10mm Thickness Acrylic Operating Voltage DC 24V
Power Supply Input 220V/110V ± 10% AC, 50 / 60Hz Power Consumption 30 Watt
Max Flow Rate 25 To 30 Person Per Minute IR Sensor Yes
Wing Height 1.5m From Ground Wing Width 270mm
High Light

electronic turnstiles

,

subway turnstile

Leave a Message
Product Description

Full height automatic smart DC brushless motor glass sliding turnstile door for security control



General introduction:

Intelligent speed gate is mainly used to prevent pedestrians illegally drilled or climbing places to implement the entrance and exit control management of high-tech products, its shape with international stainless steel profiles, fine craft, full-featured, nice, rust, durable, can resist external damage.The equipment integration mechanical, electronic, microprocessor control of electronic ticket system, access control attendance system, parking system, face recognition system, anti-static, fingerprint, palm, iris and other biometric identification system integration and use.



Product photo



Smart DC Brushless Motor Turnstile Access Control System For Security Control 0



Functions & Features:



1. Provide normally open / normally close to satisfy management request.
2. Compatible with RF card readers, bar code readers, biometric readers, push button...
3. Equipped with infrared photocell, alarm while unauthorized entry or tailgating attempts, together with anti-strike function to protect pedestrian.
4. Expanded to automatic identification system, access control system, Traffic control, attendance check and fare collection system etc.
5. Automatically reset : lock automatically while the pedestrian not pass the lane in the pre-set time after the flap opened. The passing time is adjustable.
6. Equipped with international interface, can be easily integrated with other R/W device and managed through remote supervision computer
7. Support gate open while power failure and recover N/C mode after power on.
8. (Optional) Memory function. Can pass N pedestrians continuously by swiping card N times correspondingly (N<=16)
9. (Optional) Reversed passing alarm function, barrier will alarm if pedestrian pass from opposite direction after reading the card.
10. One direction or bi-direction is optional.

12. Direction display to guide passenger which direction is to go.
13. Card-reading with memory or without memory function.
14. Flap barrier can control the population inside in the control of software.
15. Stable running with little noise.



Production dimension:

Smart DC Brushless Motor Turnstile Access Control System For Security Control 1



Technicial specifications:



Housing size
1400 long * 300 wide * 1000 high (MM)
Working direction

Single or bi-direction
Housing material
304 Stainless steel with the thickness of 1.5mm
Power supply
AC200±10%V/50±10%Hz
Driving electromotor
24V DC
Input interface
relay switch signal or 12V level signal or pulse width> 100ms 12V pulse signal, drive current> 10mA
LED indicator
2
Card reader windows
2
Pass speed
40 persons/min (normal open),25~30 persons/min(normal close)
Gate open, off time
1~2s
The time required to enter the state after power on
3s
Working environment
Indoor, outdoor (with a tent over)
Temperature
-20℃ to 60℃
Relative humidity
≤ 90%, no condensation





Case reference:



Smart DC Brushless Motor Turnstile Access Control System For Security Control 2

Smart DC Brushless Motor Turnstile Access Control System For Security Control 3
