Thickness 1.2mm Rfid Card Waist Height Turnstile Door Entry SUS304

Thickness 1.2mm Rfid Card Waist Height Turnstile Door Entry SUS304

  • Thickness 1.2mm Rfid Card Waist Height Turnstile Door Entry SUS304
  • Thickness 1.2mm Rfid Card Waist Height Turnstile Door Entry SUS304
Thickness 1.2mm Rfid Card Waist Height Turnstile Door Entry SUS304
Product Details:
Place of Origin: SHENZHEN, CHINA
Brand Name: SINOMATIC
Certification: CE/ ISO
Model Number: SN-HHT01
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: WOODEN
Delivery Time: 5-7 working days after payment received for sample
Payment Terms: T/T, Western Union, MoneyGram, Credit card
Supply Ability: 3,000pcs per month
Contact Now
Detailed Product Description
Main Material: 304 Stainless Steel (default) Barrier Lenght: 450mm To 500mm
Power Supply: AC220V/110V,50/60Hz Driving Voltage: 24V
Thickness Of Housing: 1.2mm Warranty: At Least 12 Months
High Light:

Rfid Card Waist Height Turnstile

,

Thickness 1.2mm Waist Height Turnstile

,

SUS304 Access Control Turnstile

Rfid Smart Card Door Entry Access Control Waist Height Turnstile Manufacturer



Product description



Sinomatic Waist height rotor turnstile, the whole profile is stamped from the standard SS304, beautiful and

generous shape, rust proof, durable, resisting external damage.The passageway composed of rectangular

frame and barrier arm can provide orderly and civilized access for the pedestrians, prevent illegal access.



The product adopt the most advanced drive control technology, which can be meet the various requirements

of different modern buildings styles for intelligent access control systems by changing the design range widely.



The turnstile designed for the pedestrians automatic access, with the highly perfect system, has the extensive

usability, convenient for compating IC card, ID card, bar code dimension code, fingerprint, ID card and other

card readert identification equipment, to achieve the access intelligent control and management.





Introduction of half height turnstile gate



1. Unique two-way anti-reverse function.
2. Anti-rushing function ,when the gate signal is not received, the turnstile arms locked automatically
3. The center rotor will be set free (default) or locked (optional) automatically when the power is off.



Applications of half height turnstile gate



Sinomatic half height turnstile can be widely used in places like stadium, hotel, hospital, school, airport, metro

station, bus station, park, supermarket, swimming pool, library, museum, book store, commercial center etc.



Features of half height turnstile gate



1. Cabinet is made of 304 or 316 stainless steel.



2. Mechanical drive unit with solenoid locking mechanism eliminate the use of expensive electric motor and

reduce maintenance cost.


3. If arm rotated more than half, it will auto-rotate to the next idle position. If arm rotated less than half, it will

auto-rotate back to the current idle position.


4. Built in adjustable tensioner to control rotation force to minimize over rotation. Arm just need to be pushed

lightly to rotate therefore even elderly or children are able to use the turnstile.


5. Turnstile can be configured to be bi-directional or uni-directional. Housing is locked with special key to avoid

tampering.


6. Innovative and unique mounting surface ensures simple and convenient installation for system integrator.


7. Can be used with variety of access control devices: IC / ID card readers, bar-code scanner, fingerprints, etc.

(Access controller needed)


8. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds),

the system will cancel the authority of the current user automatically.


9. The mechanism is equipped with an automatic regulated hydraulic buffer device. There is no noise and impact

when running.



10. with automatic reset function, open the gate, the system will automatically cancel the user's access authority

if the pedestrians no going through in the set time, automatic reset in 5 seconds after open.



11. The barrier arm automatically unlocing and rotating when power off, automatically locked when power on



12. Available connetion with access control system, consumer systems, electronic ticket system biometric system

static tester and other equipments.



13. Unique two-direction anti-reverse function



14. Single-direction or Bi-direction control pedestrians access.



15. Available for remote control and management directly by computer.



Technical parameters



Item Specification
Power supply AC220±10%V 50Hz/AC110±10% 60Hz
Power consumption 40W
Access device input voltage

Dry contact or 12V electrical level signal

or > 100ms 12V impulse signal, driving current > 10mA

Motor No motor
Max flow rate 30 person per minute
Arm length 45cm
Working temperature -20°C~60°C
Input voltage 100V~240V
Driving voltage 24V
Equipment power 30W
Response time 0.2S
Passing speed 30 people / min
Communication distance less than 1200m
Open signal input dry contact
Switching door time Less than 1S





Thickness 1.2mm Rfid Card Waist Height Turnstile Door Entry SUS304 0





SINOMATIC Service


1. Any inquiries will be replied within 24 hours
2. Professional maufacturer. Welcome to visit our factory.
3. OEM/ODM available
You can have your own fashionable design at reasonable& competitive price
5. High quality:
1.) All products are stictly checked in warehouse before packing
2.) All products are well-packed before shipping
3.) All products have at least 1 year warranty
6.Payment:
T/T, Western Union, Paypal, Moneygram can be accepted
7. short lead time:
Sample order in stock, and 3--7 days for bulk production
8. Shipping:
Cooperate well with DHL, EMS, UPS, FEDEX, China Air Post
You can also choose your own shipping forwarder
